performance. Webthru can transmit up to 30 frames per second, but total frames transmitted by all 6 channels
cannot surpass the maximum rate of 30 fps.
(3) Camera selection
Select cameras to monitor. User may select one specific camera or all 6 cameras.
(4) Transmission Control Gray Mode On
Images are displayed in black and white. Images can be transmitted at a higher speed under gray mode.
Single Shot Mode On
When this button is clicked, one frame of image is reproduced. Therefore, no other images may be viewed.
Channel Rotate Mode On
Images are viewed one after another as channel number. It may be configured by second.
(5) Play Control Pan/Tilt
To move the direction of external camera to where to want to see.
Zoom
To zoom the image in and out.
Focus
To control and optimize the image's focus.
Accel. Rate
To control the moving speed of the Pan / Tilt mechanism. There are three settings. "Accel." does not control
zooming speed. This can be adjusted with the mouse. By clicking the right mouse button on the image, a pop-
menu with five options will appear. The "Focus Sensitivity" controls zooming speed from level 1 to 10.
Play/Stop: Webthru generates and transfers the real-time images as soon as it is accessed. To stop transferring
images, click the "Stop" button. To resume transfer, click "Play" button.
(6) Other Function Buttons
Capture
To save a frame of still image transmitted from Webthru. A still image can be saved as a format of bitmap
(*.bmp) or Wavelet method file (*.eye). Wavelet compression image file can be decompressed and
reproduced on Internet browsers such as Explorer. Another method to capture a still image is: Place the mouse
on the image; Click the right mouse button; Select the "Save As File" option from the pop-up menu.
Server-Push Viewer
To go to the server-push viewer.
FAQ
It lists frequently asked questions and answers.
15
Webthru SWC 306 User's Guide
