(8) Placing a company logo
The Webthru logo, located on the left bottom of the viewer, can be replaced with a different company logo.

2) Real time monitoring through Default Multi Viewer

(1) Single View / Multi View
You can select a mode between single view and multi view. The button is toggled between the two functions.
(2) Play/Stop
Webthru generates and transfers six real-time images as soon as it is accessed. To stop transferring images,
click the "Stop" button. To resume transfer, click "Play" button.
(3) Camera selection
Select the camera to configure a frame rate.
(4) Frame Rate
Control image transmission speed. "Fastest," will receive images at the fastest speed possible within the
network environment. The transmission speed is dependent on the network line's capacity and user PC's
performance. Webthru can transmit up to 30 frames per second, but total frames transmitted by all 6 channels
cannot surpass the maximum rate of 30 fps.

3) Real time monitoring through Server Push Viewer

If Webthru is installed on a network where firewall is, you may access Webthru through server-push viewer
to monitor real-time images.
(1)
(2)
(3)
(4)
(1) Image Control
Extension menu is not supported.
Image Size
Select the level of resolution from 5 levels (720x486, 720x243, 360x243, 180x121, 90x60). Higher-
resolution images are larger file sizes and are transmitted at slower speed.
17
Webthru SWC 306 User's Guide
