SediGraph III 5120 Service
The rear panel is a removable panel which allows access to the 24VDC and the Quad
switching power supplies used in the instrument. There are cut-outs in this panel to allow air
flow out of the instrument.
Cooling air is drawn into the instrument from two fan assemblies on the bottom, passed over
the internal components, and vented to the outside through the rear panel. The X-ray tube
cooling fan has an aluminum deflector which forces air across the tube for extra cooling
capability. There are sensors to alert the operator if a fan has lost 30% of its power.
Fluid Module Cover
A cover houses the fluid module and the mixing chamber, and helps with noise abatement.
Mar 2010
Cabinetry
2-3
