Fluid module

Fluid Module Serviceable items

Mixing Chamber

511/25870/00 Aluminum, (Standard) large bore
511/25870/02 Stainless Steel, for high PH or caustics, large bore
511/25875/00 Aluminum, small bore tubing
511/25875/02 Stainless Steel, for high PH or caustics, small bore
510/60817/00 Cable assembly

Valve assemblies

512/34011/00 Waste and rinse valve assemblies (complete assembly)
512/34012/00 Air valve assembly (complete assembly)
512/60837/00 Assembly, cable valve (motor and coupling)

Pumps/Stirrer

512/62800/00 EZ Load pump head
511/25889/00 Pump motor
512/34005/00 Assembly, Magnetic Stirrer
2-10
SediGraph III 5120 Service
Mar 2010
