Remove the Side Plate Screws
After removing the cover screws remove both of the top and bottom Side Plate screws using the long
portion of the "L" TORX wrench. Retain the Side Plate screw for re-installation. The image below shows
the removal of the top Side Plate screw.
Remove the bottom Side Plate screw once the top Side Plate screw has been removed.
After removing the Set, Cover and Side plate screws, the corner of your FLEX-6000 should look like the
image below.
Page 5
© 2013 FlexRadio Systems
