janitza UMG 511 Manual page 19

Address Format
4323 float
4325 float
4327 float
4329 float
4331 float
4333 float
4335 float
4337 float
4339 float
4341 float
4343 float
4345 float
4347 float
4349 float
4351 float
4353 float
4355 float
4357 float
4359 float
4361 float
4363 float
4365 float
4367 float
4369 float
4371 float
4373 float
4375 float
4377 float
4379 float
4381 float
4383 float
4385 float
4387 float
4389 float
4391 float
4393 float
4395 float
4397 float
4399 float
4401 float
4403 float
4405 float
4407 float
4409 float
4411 float
4413 float
4415 float
4417 float
4419 float
4421 float
4423 float
4425 float
4427 float
4429 float
4431 float
4433 float
4435 float
4437 float
4439 float
Designation
_ULL_UNDER_AVG[2]
_ULL_NEG_PEAK_AVG[0]
_ULL_NEG_PEAK_AVG[1]
_ULL_NEG_PEAK_AVG[2]
_ULL_POS_PEAK_AVG[0]
_ULL_POS_PEAK_AVG[1]
_ULL_POS_PEAK_AVG[2]
_ULL_PEAK_PEAK_AVG[0]
_ULL_PEAK_PEAK_AVG[1]
_ULL_PEAK_PEAK_AVG[2]
_U_STERN_AVG
_U_SYM_AVG
_FREQ_AVG
_NORM_FREQ_AVG
_PLN_AVG[0]
_PLN_AVG[1]
_PLN_AVG[2]
_PLN_AVG[3]
_P_SUM_AVG
_Q_SUM_AVG
_QLN_AVG[0]
_QLN_AVG[1]
_QLN_AVG[2]
_QLN_AVG[3]
_P_SUM3_AVG
_Q_SUM3_AVG
_ILN_AVG[0]
_ILN_AVG[1]
_ILN_AVG[2]
_ILN_AVG[3]
_SLN_AVG[0]
_SLN_AVG[1]
_SLN_AVG[2]
_SLN_AVG[3]
_I_SUM3_AVG
_I_SUM_AVG
_S_SUM3_AVG
_S_SUM_AVG
_THD_IL_AVG[0]
_THD_IL_AVG[1]
_THD_IL_AVG[2]
_THD_IL_AVG[3]
_ZHD_IL_AVG[0]
_ZHD_IL_AVG[1]
_ZHD_IL_AVG[2]
_ZHD_IL_AVG[3]
_ILN_CF_AVG[0]
_ILN_CF_AVG[1]
_ILN_CF_AVG[2]
_ILN_CF_AVG[3]
_IN_AVG
_IM_AVG
_IG_AVG
_I_SYM_AVG
_ILN_OVER_AVG[0]
_ILN_OVER_AVG[1]
_ILN_OVER_AVG[2]
_ILN_OVER_AVG[3]
_ILN_UNDER_AVG[0]
Modbus address list
Unit Note
%
V
V
V
V
V
V
V
V
V
V
%
Hz
Hz
W
W
W
W
W
var
var
var
var
var
W
var
A
A
A
A
VA
VA
VA
VA
A
A
VA
VA
%
%
%
%
%
%
%
%
-
-
-
-
A
A
A
%
%
%
%
%
%
UMG 511
19
