Address Format
4135 float
4137 float
4139 float
4141 float
4143 float
4145 float
4147 float
4149 float
4151 float
4153 float
4155 float
4157 float
4159 float
4161 float
4163 float
4165 float
4167 float
4169 float
4171 float
4173 float
4175 float
4177 float
4179 float
4181 float
4183 float
4185 float
4187 float
4189 float
4191 float
4193 float
4195 float
4197 float
4209 float
13017 float
13019 float
13021 float
13023 float
13025 float
13027 float
13222 float
Designation
_ULL_PEAK_PEAK[0]
_ULL_PEAK_PEAK[1]
_ULL_PEAK_PEAK[2]
_ULL_UNDER[0]
_ULL_UNDER[1]
_ULL_UNDER[2]
_ULL_OVER[0]
_ULL_OVER[1]
_ULL_OVER[2]
_FLI_PF5[0]
_FLI_PF5[1]
_FLI_PF5[2]
_FLI_PF5[3]
_FLI_SHORT_TERM[0]
_FLI_SHORT_TERM[1]
_FLI_SHORT_TERM[2]
_FLI_SHORT_TERM[3]
_FLI_LONG_TERM[0]
_FLI_LONG_TERM[1]
_FLI_LONG_TERM[2]
_FLI_LONG_TERM[3]
_URC[0]
_URC[1]
_URC[2]
_URC[3]
_IRC[0]
_IRC[1]
_IRC[2]
_IRC[3]
_ULLRC[0]
_ULLRC[1]
_ULLRC[2]
_TEMPERATUR
_IRATED_TDD[0]
_IRATED_TDD[1]
_TDD_IL[0]
_TDD_IL[1]
_TDD_IL[2]
_TDD_IL[3]
_U_SYM_U0
Modbus address list
Unit Note
V Peak-peak value, U L1-L2
V Peak-peak value, U L2-L3
V Peak-peak value, U L3-L1
% Under difference, U L1-L2 (61000-4-30)
% Under difference, U L2-L3 (61000-4-30)
% Under difference, U L3-L1 (61000-4-30)
% Over difference, U L1-L2 (61000-4-30)
% Over difference, U L2-L3 (61000-4-30)
% Over difference, U L3-L1 (61000-4-30)
Current flicker Pf5, L1-N
Current flicker Pf5, L2-N
Current flicker Pf5, L3-N
Current flicker Pf5, L4-N
Short-term flicker level, Pst (10m), L1-N
Short-term flicker level, Pst (10m), L2-N
Short-term flicker level, Pst (10m), L3-N
Short-term flicker level, Pst (10m), L4-N
Long-term flicker level, Plt (2h), L1-N
Long-term flicker level, Plt (2h), L2-N
Long-term flicker level, Plt (2h), L3-N
Long-term flicker level, Plt (2h), L4-N
V Ripple control signal, U L1-N,
(61000-4-30)
V Ripple control signal, U L2-N,
(61000-4-30)
V Ripple control signal, U L3-N,
(61000-4-30)
V Ripple control signal, U L4-N,
(61000-4-30)
A Ripple control signal, I L1
A Ripple control signal, I L2
A Ripple control signal, I L3
A Ripple control signal, I L4
V Ripple control signal, U L1-L2,
(61000-4-30)
V Ripple control signal, U L2-L3,
(61000-4-30)
V Ripple control signal, U L3-L1,
(61000-4-30)
°C Internal temperature
A Maximum demand load current, L1..L3
A Maximum demand load current, L4
% TDD, Total Demand Distortion, IlL1
% TDD, Total Demand Distortion, IlL2
% TDD, Total Demand Distortion, IlL3
% TDD, Total Demand Distortion, IlL4
% Unsymmetrical; voltage U0
UMG 511
17
