Other Values - janitza UMG 511 Manual

Modbus address list
Address Format

Other values

6706 float
6708 short
6709 short
6710 short
6711 short
6712 short
6713 short
6714 short
6715 short
6716 short
6717 short
6718 short
6719 short
6720 short
6721 uint
6723 uint
6725 uint
6727 uint
6729 uint
6731 uint
6733 uint
6735 uint
6737 uint
6739 uint
6741 short
6742 short
6743 short
6744 string
6776 float
6778 float
6780 float
6782 float
6784 float
6786 float
6788 float
6790 float
6792 float
6794 float
6796 float
6798 float
6800 float
6802 float
6804 float
6806 float
6808 float
6810 float
6812 float
6814 float
6816 float
6818 float
6820 float
6822 float
6824 float
6826 float
6828 float
6830 float
UMG 511
44
Designation
_SPU012
_DIGOUT_STAT[0]
_DIGOUT_STAT[1]
_DIGOUT_STAT[2]
_DIGOUT_STAT[3]
_DIGOUT_STAT[4]
_DIGIN_STAT[0]
_DIGIN_STAT[1]
_DIGIN_STAT[2]
_DIGIN_STAT[3]
_DIGIN_STAT[4]
_DIGIN_STAT[5]
_DIGIN_STAT[6]
_DIGIN_STAT[7]
_EVT_COUNT
_FLAG_COUNT
_TRANS_COUNT
_HWW_COUNT
_RX232_COUNT
_TX232_COUNT
_ERR232_COUNT
_RX485_COUNT
_TX485_COUNT
_ERR485_COUNT
_DEL_WH
_DEL_QH
_INIT_MAX
_RUN
_CTPRIM[0]
_CTPRIM[1]
_CTSEC[0]
_CTSEC[1]
_VTPRIM[0]
_VTPRIM[1]
_VTSEC[0]
_VTSEC[1]
_IRATED[0]
_IRATED[1]
_NOMINAL_U[0]
_NOMINAL_U[1]
_NOMINAL_I[0]
_NOMINAL_I[1]
_TRNS_DELTA[0]
_TRNS_DELTA[1]
_TRNS_I_ABS[0]
_TRNS_I_ABS[1]
_TRNS_U_ABS[0]
_TRNS_U_ABS[1]
_I_EVT_MAX[0]
_I_EVT_MAX[1]
_U_EVT_MAX[0]
_U_EVT_MAX[1]
_U_EVT_MIN[0]
_U_EVT_MIN[1]
_U_EVT_OFF[0]
_U_EVT_OFF[1]
Unit Note
V Star connection voltage
n Status Digital Output 1
0=not active, 1=active
n Status Digital Output 2
n Status Digital Output 3
n Status Digital Output 4
n Status Digital Output 5
n Status Digital Input 1
0=not active, 1=active
n Status Digital Input 2
n Status Digital Input 3
n Status Digital Input 4
n Status Digital Input 5
n Status Digital Input 6
n Status Digital Input 7
n Status Digital Input 8
n Event counter
n Flag counter
n Error counter, transients
n Error counter, half-cycle effective values
n Error counter, receive RS232
n Error counter, send RS232
n Error counter, RS232
n Error counter, receive RS485
n Error counter, send RS485
n Error counter, RS485
1= Delete all real energy counters
1= Delete all reactive energy counters
Only for internal use
64 Only for internal use
A L1, L2, L3; Current transformer, primary
A L4; Current transformer, primary
A L1, L2, L3; Current transf., secondary
A L4; Current transformer, secondary
V L1, L2, L3; Voltage transformer, primary
V L4; Voltage transformer, primary
V L1, L2, L3; Voltage transformer, primary
V L4; Voltage transformer, primary
A Nominal current transf.; I L1, I L2, I L3
A Nominal current transformer; I L4
V Nominal voltage; L1, L2, L3
V Nominal voltage; L4
A Nominal current; L1, L2, L3
A Nominal current; L4
% Only for internal use
% Only for internal use
% Only for internal use
% Only for internal use
% Only for internal use
% Only for internal use
% Only for internal use
% Only for internal use
% Only for internal use
% Only for internal use
% Only for internal use
% Only for internal use
% Only for internal use
% Only for internal use
