External Variable Speed Pump Hookup
Other variable speed pumps compatible with the MultiWave receiver include Jandy
Marathon
, Century
®
NOTE: A CAT5-568B network cable is required to route between the P5043ME Expansion
Module and the variable speed pump.
Insert the network cable into the Motor Control Input as shown in Figure 5-4.
1.
Cut off the second RJ45 connector from the other end of the cable and strip each connector
2.
wire.
Refer to the applicable figure for the variable speed pump manufacturer (Figure 4-12 to
3.
Figure 4-15) to connect the wires to the expansion module.
and Speck
.
®
®
Filter Pump Installations
, Hayward
,
®
®
31
