PART LIST—Model No. Nº. du Modèle PFIVEX33613.0
N° Description
1 Main frame
2 Front stabilizer
3 Rear stabilizer
4 Saddle
5 Handlebar
6 L/R crank
7 L/R pedal
8 Computer cover
9 Flat washer
10 Nylon nut
11 End cap
12 Carriage bolt
13 Arc washer
14 Acorn nut
15 Knob nut
16 Saddle post
17 Bushing
18 Tension control
19 Sensor wire
20 Flat washer
21 screw
Qté. N° Description
1 22 Flat washer
1 23 Innner hex screw
1 24 Arc washer
1 25 Foam grip
1 26 Handlebar wire
1 27 Round end cap
1 28 Cross pan self -tapping screw
1 29 Cross pan screw
3 30 Small bushing
3 31 Cushion rubber
2 32 Square cap
4 33 Cap S16
4 34 Hex bolt
4 35 Flat washer
1 36 Nylon nut
1 37 Inner hex pan screw
1 38 Flat washer
1 39 Back post
1 40 Back seat
1 41 End cap
1
15
Qté.
2
4
2
2
2
2
4
2
2
1
2
1
1
2
1
4
4
1
1
2
