Specifications
Physical
Width:
Depth:
Height:
Weight:
Electrical
Adapter:
AC voltage:
DC voltage:
Power consumption:
PoE (DC)
Input voltage:
Note: Power can also be provided to the access point through the Ethernet
port based on IEEE 802.3af Power over Ethernet (PoE) specifications. When
both PoE is provided and the adapter is plugged in, PoE will be turned off.
Environmental
Temperature:
Relative humidity:
(non-condensing)
Maximum altitude:
21.832 cm (8.595 in)
13.727 cm (5.404 in)
3.27 cm (1.287 in)
0.8 kg (1.762 lbs)
100-240 volts, 0.4A, 50/60 Hz
3.3 volts, 4A
13.2 watts
48 volts, 0.27A, 12.96 watts
Operating
0°C to 55°C (32°F to 131°F)
15% to 95% at 40°C (104°F)
4.6 Km (15,000 ft)
Non-Operating
-40°C to 70°C (-40°F to 158°F)
90% maximum at 65°C (149°F)
4.6 Km (15,000 ft)
A
A-1
