Chapte 8 Video Scope
Quick Save
Press the menu button, use the left or right buttons to highlight the quick save icon and press the select button
to store a fi le image of the scope screen in the fi le folder within an active project. Scope fi les will be preceded
by a target icon.
Project Management
To open project management, press the menu button, use the left or right buttons to highlight the project
management folder icon and press select. Use the project management folder to open the project that the
scope images are to be stored. When entering the video scope function, the active folder will be the one
last used in the OTDR or LTS. For more information about the project management system, please refer to
Chapter 9 of this guide.

File Management

To open fi le management, press the menu button, use the left or right buttons to highlight the fi le management
icon and press select. Use File management to view a list of saved fi les or to open a stored image. File types
are identifi ed by the preceding icon. Trace fi les are indicated by a trace icon, LTS fi le by an LTS icon and
scope fi les are preceded by scope (target) icon
Help
Press the menu button, use the left and right buttons to highlight the help icon and press select to view the help
information.
8.4 Video Scope Operation Icon Menu
The following functions are only available for use when the video scope is in live scan mode.

Grading Rings

Used to turn on and off the rings that indicate the IEC61300-3-35 grading zones.
Enter the menu mode with the menu button, use the LRUD buttons to highlight the pass/fail grading rings
overlay icon and press the select button. Exit the menu mode and use the LRUD buttons to center the image
in the rings. Use the Pass/Fail Criteria Tables from page 44 to grade the connector end face. 2, 3, 5 and 10
micron contaminant examples are displayed just below the connector image on the video scope display.

Pass/Fail Label

Used to turn cycle through P/F (Pass/Fal) Off, P/F Man (In Red "Fail"), P/F Man (In Green "Pass") and P/F
auto. To set the pass/fail indicator, press the menu button, use the left or right buttons to highlight the pass/fail
icon and press select to cycle through the pass/fail states.
