TTI FTE6100 User Manual page 14

Chapter 7 Tunable Laser Source
7.3 TLS Touch Screen Operation
Laser Start/Stop /Activity
Indicator
Home Icon
Help Icon
Step Size
Power
Dwell Time
Output Value
Output Unit
Active Output Slide
Channel Scale
Low end Slide
High End Slice
Snap to Lowest laser Output
Snap to highest laser Output
Laser Output Down
Laser or Sweep Start/Pause
Laser Output Up
FTE-6100 User's Guide Rev A 5/2017
Flashing indicates active laser
Starts and stops laser/sweep
Brings the user back to the home page
Opens the context sensitive help menu
Cycles through available step sized in nm, Freq, and Ch
Opens numeric keypad to enter power level
Opens numeric keypad to enter dwell time or CW mode
Laser output value in nm, Freq or Ch
Indicates displayed output unit
Used to select/indicate output laser
Full scale of available laser output
Used to select lowest laser output of sweep
Used to select highest laser output of sweep
Moves the active slide to the lowest laser output set by the Low
End Slide
Moves the active slide to the highest laser output set by the High
End Slide
Moves the low end slide down the scale
Start and stops the laser/sweep
Moves the high end slide up the scale
