AdderLink Infinity browser-based configuration utility

The browser-based configuration utility within all TX and RX units requires a network
connection between the ALIF100T unit and a computer on the same network. The
configuration utility allows you to perform many important functions. Please see
Appendix A.
To connect a computer to access the configuration utility
1 Connect a CAT 5, 5e, 6, or 7 link cable to the network port on the front panel.
The port automatically configures itself, so no cross-over cable is required (but is
supported if you do use one).
2 Connect the other end of the link cable directly to the network port of your
computer.
To access the browser-based configuration utility
1 Temporarily connect the ALIF100T unit and your computer, as discussed left.
2 Run a web browser on your computer and enter the IP address of the ALIF100T unit:
169.254.1.33
Note: If the IP address of ALIF100T unit has been changed and is not known, providing it is
appropriate to do so, perform a
The opening page of the ALIF configuration utility should be displayed:
Temporary link
from your computer
to the ALIF100T
network port
You can find further information about the configuration pages later in this guide:
• Appendix A - Configuration pages
manual factory reset to restore the default address.
Use the menu options to choose
the required configuration page
8
