ADDER AdderLink Infinity 100T User Manual page 16

USB Settings
Security
Enable Dummy Boot Keyboard
When ticked, ALIF100T unit will report a virtual dummy boot keyboard to the attached PC to ensure that
a keyboard is always reported when the PC boots up. The dummy boot keyboard uses one of the 13 USB
endpoints, therefore if all 13 endpoints are required elsewhere for USB devices (or a KVM switch only supports
two HID devices) then it can be disabled by deselecting this option. See also Reserved Port Range below.
Hub Size
Using this option you can select whether ALIF100T unit should report itself as a 13 or a 7 port USB hub. Some
USB hosts are only able to support 7 port USB hubs. If this option is set to 7, then only 7 USB devices are
supported by the PC.
Reserved Port Range
For some devices, e.g. touch screens, you may wish to ensure that they are always reported to the same USB
port number so that the USB driver will always find the device. This option allows you reserve up to 8 ports
for certain devices. At the RX unit, the devices are assigned to the reserved ports. If a port reservation is to be
applied, then the dummy boot keyboard should be disabled. The default value for this option is '0', i.e. disabled.
USB Encryption
This setting determines whether encryption should be applied to the USB data passed across the link. Note
that video data is never encrypted.
Control Encryption
This setting determines whether encryption should be applied to the control data passed across the link. The
"Prefer off" setting means that control encryption is enabled if the receiver at the other end of the link has
"always on" selected, otherwise it is disabled. Note: video data is never encrypted.
Secure Web pages with password
When ticked, this option enables https security so that the configuration pages are only accessible to the admin
user with a password.
Change/confirm password
These options allow you to change the admin password for the system.
To get here
1 Connect your computer to the network port on the front panel.
2 Run a web browser and enter the IP address of the unit: http://169.254.1.33
If the address is unknown, perform a manual factory
3 Click either the USB Settings or Security links, as appropriate.
reset.
15
