IKARPC-07A-A9 In-vehicle Panel PC
MODEL:
IKARPC-07A-A9
7" Android-Based In-Vehicle Panel PC with Touchscreen
Freescale™ i.MX6 ARM Cortex™-A9 CPU, OBD-II, CAN, USB,
Audio, RS-232, RoHS Compliant, IP 54 Front Panel
User Manual
Page I
Rev. 1.02 – October 20, 2016

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the IKARPC-07A-A9 and is the answer not in the manual?

Questions and answers

Related Manuals for IEI Technology IKARPC-07A-A9

Summary of Contents for IEI Technology IKARPC-07A-A9

  • Page 1 IKARPC-07A-A9 In-vehicle Panel PC MODEL: IKARPC-07A-A9 7” Android-Based In-Vehicle Panel PC with Touchscreen Freescale™ i.MX6 ARM Cortex™-A9 CPU, OBD-II, CAN, USB, Audio, RS-232, RoHS Compliant, IP 54 Front Panel User Manual Page I Rev. 1.02 – October 20, 2016...
  • Page 2 IKARPC-07A-A9 In-vehicle Panel PC Revision Date Version Changes October 20, 2016 1.02 Modified Section 2.2: Optional Items October 28, 2015 1.01 Updated product photos June 12, 2015 1.00 Initial release Page II...

  • Page 3: Safety Instructions

    IKARPC-07A-A9 In-vehicle Panel PC Safety Instructions Warning! Read the user manual before connecting the system to the power source. Vorsicht! Bitte lesen Sie die Bedienungsanleitung, bevor Sie das System an eine Stromquelle anschließen. Attention! Avant de brancher le système à la source d'alimentation, consultez le mode d'emploi.
  • Page 4 IKARPC-07A-A9 In-vehicle Panel PC Warning! Use only the adapter and power cord approved for this system. Use of another type of adapter may risk fire or explosion. Please refer to the user manual for the power adapter specifications. Vorsicht! Nur zugelassene Netzteile und Netzkabel dürfen verwendet werden. Die Benutzung von anderen Netzteilen kann einen Brand oder eine Explosion zur Folge haben.
  • Page 5 IKARPC-07A-A9 In-vehicle Panel PC Copyright COPYRIGHT NOTICE The information in this document is subject to change without prior notice in order to improve reliability, design and function and does not represent a commitment on the part of the manufacturer. In no event will the manufacturer be liable for direct, indirect, special, incidental, or consequential damages arising out of the use or inability to use the product or documentation, even if advised of the possibility of such damages.
  • Page 6 IKARPC-07A-A9 In-vehicle Panel PC Manual Conventions WARNING Warnings appear where overlooked details may cause damage to the equipment or result in personal injury. Warnings should be taken seriously. CAUTION Cautionary messages should be heeded to help reduce the chance of losing data or damaging the product.

  • Page 7: Table Of Contents

    IKARPC-07A-A9 In-vehicle Panel PC Table of Contents 1 INTRODUCTION......................1 1.1 O ........................2 VERVIEW 1.2 F ........................2 EATURES 1.3 F ......................3 RONT ANEL 1.3.1 LED Indicators....................4 1.4 R ....................... 4 ANEL 1.5 R ..................... 6 IGHT ANEL 1.6 T...
  • Page 8 IKARPC-07A-A9 In-vehicle Panel PC 4 USING THE IKARPC-07A-A9 .................. 27 4.1 P ................... 28 OWER ROCEDURE 4.1.1 Installation Checklist ..................28 4.1.2 Power-on Procedure ..................28 4.1.3 Power-off Procedure ..................30 4.2 H ......................31 CREEN 4.2.1 Navigation Buttons................... 31 4.2.2 Multiple Home Screens ..................
  • Page 9 IKARPC-07A-A9 In-vehicle Panel PC 5.2.1 Camera Connector (CAMERA1) ..............57 5.2.2 LED Connector (LED_BD2)................57 5.2.3 LVDS Connector (CN2) ................... 58 5.2.4 Microphone Connector (MIC1) ............... 58 5.2.5 Programming Connector (MCU1)..............59 5.2.6 Programming Connector (JP2) ............... 59 5.2.7 Speaker Connector (SPK1) ................59 5.2.8 Touch Panel Connector (CN10)...............
  • Page 10 IKARPC-07A-A9 In-vehicle Panel PC List of Figures Figure 1-1: IKARPC-07A-A9 Panel PC ..................2 Figure 1-2: Front View ........................3 Figure 1-3: LED Indicators......................4 Figure 1-4: Rear View ........................5 Figure 1-5: Right Side Panel......................6 Figure 1-6: Top Panel ........................6 Figure 1-7: Bottom Panel .......................7 Figure 1-8: Dimensions (unit: mm) .....................10...
  • Page 11 IKARPC-07A-A9 In-vehicle Panel PC Figure 4-11: Status Bar – Notification ..................36 Figure 4-12: Wireless and Networks Settings ................37 Figure 4-13: More Settings Menu ....................38 Figure 4-14: Sound Menu......................39 Figure 4-15: Display Menu ......................40 Figure 4-16: Storage Menu ......................41 Figure 4-17: Apps Menu.......................42 Figure 4-18: Users Menu......................42...
  • Page 12 IKARPC-07A-A9 In-vehicle Panel PC List of Tables Table 1-1: Technical Specifications....................9 Table 2-1: Packing List.........................13 Table 2-2: Optional Items......................14 Table 3-1: IO 1 Connector Pinouts....................21 Table 3-2: IO 2 Connector Pinouts....................22 Table 3-3: Video Input Connector Pinouts.................23 Table 3-4: Power Input Connector Pinouts................24 Table 4-1: Power State and Ignition System................29...

  • Page 13: Introduction

    IKARPC-07A-A9 In-vehicle Panel PC Chapter Introduction Page 1...

  • Page 14: Overview

    1.1 Overview Figure 1-1: IKARPC-07A-A9 Panel PC The IKARPC-07A-A9 is a 7” Android-based panel PC designed for in-car use. At the heart of the system is the Freescale™ i.MX6 ARM Cortex™-A9 processor, offering low power in a powerful package. The system also offers a multimedia experience with a built-in camera, microphone and speaker.

  • Page 15: Front Panel

    IP 54 compliant front panel  RoHS compliance  1.3 Front Panel The front of the IKARPC-07A-A9 is a flat panel screen with a plastic frame. The components on the front panel are listed below:  5-megapixel camera  Ambient light sensor ...

  • Page 16: Led Indicators

    IKARPC-07A-A9 In-vehicle Panel PC 1.3.1 LED Indicators The LED indicators on the front panel show the status of power, Bluetooth, Wi-Fi and GPRS/HSUPA connection. Figure 1-3: LED Indicators 1.4 Rear Panel The rear panel has VESA mounting screw holes and an access panel for SD card and SIM card.

  • Page 17: Figure 1-4: Rear View

    IKARPC-07A-A9 In-vehicle Panel PC  1 x 3.75G antenna connector  1 x GPS antenna connector Figure 1-4: Rear View Page 5...

  • Page 18: Right Side Panel

    IKARPC-07A-A9 In-vehicle Panel PC 1.5 Right Side Panel The right side panel has one USB 2.0 host port. Figure 1-5: Right Side Panel 1.6 Top Panel The top panel has a power button. Press the power button for 4~6 seconds to power on the system.

  • Page 19: Bottom Panel

    1.7 Bottom Panel The bottom panel has a 2 W speaker. Figure 1-7: Bottom Panel 1.8 System Specifications The technical specifications for the IKARPC-07A-A9 systems are listed in Table 1-1. System Freescale™ i.MX6 ARM Cortex™-A9 processor Memory On-board 1 GB SDRAM memory...
  • Page 20 IKARPC-07A-A9 In-vehicle Panel PC Communication 1 x 10/100 Mbps Wireless LAN 802.11a/b/g/n Bluetooth Bluetooth 4.0 + HS WWAN Built-in u-blox LISA-U200-02S 3.75G UMTS/HSPA+ module supports: HSPA/UMTS-800/850/1900/2100 MHz Quad-band EDGE/GPRS/GSM-850/900/1800/1900MHz Built-in u-blox NEO-M8N GPS module with external antenna RFID On-board RFID antenna 13.56MHz protocols supported:...

  • Page 21: Table 1-1: Technical Specifications

    IKARPC-07A-A9 In-vehicle Panel PC I/O Ports 1 x 9 V~ 30 V DC input connector 1 x USB host port 20-pin connector: 1 x 10/100 Mbps LAN 1 x CAN 2.0 B 1 x OBD-II 1 x USB 24-pin connector:...

  • Page 22: Dimensions

    IKARPC-07A-A9 In-vehicle Panel PC 1.9 Dimensions The dimensions are shown below. Figure 1-8: Dimensions (unit: mm) Page 10...

  • Page 23: Unpacking

    IKARPC-07A-A9 In-vehicle Panel PC Chapter Unpacking Page 11...

  • Page 24: Packing List

    If any of the components listed in the checklist below are missing, do not proceed with the installation. Contact the IEI reseller or vendor the IKARPC-07A-A9 was purchased from or contact an IEI sales representative directly by sending an email to ales@ieiworld.com.

  • Page 25: Optional Items

    IKARPC-07A-A9 In-vehicle Panel PC The IKARPC-07A-A9 is shipped with the following components: Quantity Item Image IKARPC-07A-A9 in-vehicle panel PC ACC power cable (P/N: 32002-001900-100-RS) GPS/GSM antenna (P/N: 32506-000100-100-RS) User manual CD and driver CD Table 2-1: Packing List 2.2 Optional Items...

  • Page 26: Table 2-2: Optional Items

    IKARPC-07A-A9 In-vehicle Panel PC Item Image Cigarette lighter power cable (P/N: 32002-004000-100-RS) I/O connector 1 cable (20-pin) (P/N: 19800-021900-100-RS) I/O connector 2 cable (24-pin) (P/N: 32024-002900-100-RS) Video input cable (8-pin) (P/N: 19800-022000-100-RS) VESA mount stand (138 mm) (P/N: IVI-MK03-R10) Table 2-2: Optional Items If any of these items are missing or damaged, contact the distributor or sales representative immediately.

  • Page 27: Installation

    IKARPC-07A-A9 In-vehicle Panel PC Chapter Installation Page 15...

  • Page 28: Anti-Static Precautions

    IKARPC-07A-A9 and severe injury to the user. Electrostatic discharge (ESD) can cause serious damage to electronic components, including the IKARPC-07A-A9. Dry climates are especially susceptible to ESD. It is therefore critical that whenever the IKARPC-07A-A9 is accessed internally, or any other electrical component is handled, the following anti-static precautions are strictly adhered ...

  • Page 29: Installation And Configuration Steps

    IKARPC-07A-A9 In-vehicle Panel PC  Anti-static Discharge: If a user open the rear panel of the flat panel PC, to configure the jumpers or plug in added peripheral devices, ground themselves first and wear an anti-static wristband. 3.3 Installation and Configuration Steps The following installation steps must be followed.

  • Page 30: Sim Card Installation

    IKARPC-07A-A9 In-vehicle Panel PC Locate the SD card slot. Insert the SD card into the slot to install it. To remove Step 2: the SD card, push the SD card inward to release it. Figure 3-2: Install SD Card Replace the SD card slot access panel.

  • Page 31: Figure 3-4: Install Sim Card

    Replace the SIM card slot access panel. Step 3: Step 0: WARNING: The IKARPC-07A-A9 is not compatible with a micro-SIM (3FF) adapter or a nano-SIM (4FF) adapter. Please install a mini-SIM (2FF or Standard SIM) card for proper network connection. Page 19...

  • Page 32: Mounting The System

    3.6 Mounting the System The IKARPC-07A-A9 is VESA (Video Electronics Standards Association) compliant and can be mounted on a mounting device with a 75 mm interface pad. The IKARPC-07A-A9 VESA mount retention screw holes are shown in Figure 3-5. Refer to the installation documentation that came with the mounting device to mount the IKARPC-07A-A9.

  • Page 33: External I/O Connectors

    IKARPC-07A-A9 In-vehicle Panel PC 3.7 External I/O Connectors This section provides an overview of the external I/O connectors of the IKARPC-07A-A9. 3.7.1 I/O Connector 1 (20-pin) The 20-pin I/O connector (IO 1) supports the following external peripheral devices:  1 x 10/100 Mbps LAN 1 x CAN 2.0 B...

  • Page 34: I/O Connector 2 (24-Pin)

    IKARPC-07A-A9 In-vehicle Panel PC 3.7.2 I/O Connector 2 (24-pin) The 24-pin I/O connector (IO 2) supports the following external peripheral devices:  1 x Audio line-out (R+L)  1 x Audio line-in  1 x RS-232  2-bit digital input ...

  • Page 35: Video Input Connector

    Please refer to Section 4.4.2 for detail information. 3.7.3 Video Input Connector The IKARPC-07A-A9 has one 8-pin video input connector on the rear panel. The pinouts for the video input connector are listed in the figure and table below. Figure 3-8: Video Input Connector PIN NO.

  • Page 36: Power Input Connection

    DESCRIPTION POWER Table 3-4: Power Input Connector Pinouts The IKARPC-07A-A9 can use either ACC power or DC power from the vehicle. To use ACC power, connect the IKARPC-07A-A9 to the vehicle through the ACC power cable. See Figure 3-10. Figure 3-10: ACC Power Cable...

  • Page 37: Usb Connector

    Figure 3-11: Optional Cigarette Lighter Cable 3.7.5 USB Connector The IKARPC-07A-A9 has one USB 2.0 port on the right side panel. The USB port has a screw on the side for securing the USB devices, such as barcode scanners and smart card readers.

  • Page 38: System Maintenance

    IKARPC-07A-A9 In-vehicle Panel PC 3.8 System Maintenance If the components of the IKARPC-07A-A9 fail, they must be replaced. Please contact the system reseller or vendor to purchase the replacement parts. NOTE: A user cannot replace a motherboard. If the motherboard fails it must be shipped back to IEI to be replaced.

  • Page 39: Using The Ikarpc-07A-A9

    IKARPC-07A-A9 In-vehicle Panel PC Chapter Using the IKARPC-07A-A9 Page 27...

  • Page 40: Power-On/Off Procedure

    Step 1: from the IKARPC-07A-A9 to the vehicle. See Section 3.7.4. Start the vehicle, and the IKARPC-07A-A9 will be turned on automatically after Step 2: 10 seconds. The power LED lights up in blue when the system is turned on. The user can also hold down the power button on the top panel for 4~6 seconds to turn on the system when the key is in ACC or ON position.

  • Page 41: Figure 4-1: Power Connector And Power Button

    IKARPC-07A-A9 In-vehicle Panel PC LOCK START ACC Signal Car Cigarette Lighter 5 V Standby Power On after 1 second Auto Start-up After 10 seconds Auto Shut-down After 5 seconds Table 4-1: Power State and Ignition System Figure 4-1: Power Connector and Power Button The system starts booting.

  • Page 42: Power-Off Procedure

    IKARPC-07A-A9 In-vehicle Panel PC 4.1.3 Power-off Procedure To power-off the IKARPC-07A-A9 please follow the steps below: (1) Turn off the vehicle, or Step 1: (2) Hold down the power button for 4~6 seconds to turn off the system. The power-off confirmation window appears. Tap OK to turn off the system.

  • Page 43: Home Screen

    IKARPC-07A-A9 In-vehicle Panel PC 4.2 Home Screen The IKARPC-07A-A9 has multiple home screens allowing users to customize the screen with widgets, apps, folders and shortcuts. The following sections describe the basic technique to manage the home screen. 4.2.1 Navigation Buttons The IKARPC-07A-A9 Android home screen has three navigation buttons to control the system.

  • Page 44: Multiple Home Screens

    IKARPC-07A-A9 In-vehicle Panel PC 4.2.2 Multiple Home Screens Swipe left or right to switch. Long press an item on the home screen and when it vibrates drag the item to other screen. Figure 4-4: Multiple Home Screens 4.2.3 Adding Shortcut To add app or widget shortcuts on the home screen, follow the steps below.

  • Page 45: Favorites Tray

    IKARPC-07A-A9 In-vehicle Panel PC Long press an app icon or a widget (click the WIDGETS tab to access the Step 2: widgets page). When it vibrates, drag app/widget to the home screen. Figure 4-6: Launcher Page 4.2.4 Favorites Tray The Favorites tray at the side of each home screen allows users to keep the most important or frequently used shortcuts and folders.

  • Page 46: Arranging Home Screen

    IKARPC-07A-A9 In-vehicle Panel PC 4.2.5 Arranging Home Screen The items on the home screen can be moved and deleted. Long press an item on the home screen. When it vibrates, drag it where you want. To trash the item on the desktop, drag it to the “X”...

  • Page 47: Status Bar

    IKARPC-07A-A9 In-vehicle Panel PC 4.3 Status Bar The status bar on the top of the screen (Figure 4-9) displays the pending notifications and status, such as battery level or signal strength. Figure 4-9: Status Bar Swipe down from the right of the status bar to view the setting shortcut.

  • Page 48: Settings

    Swipe down from the left of the status bar to view notification details. Figure 4-11: Status Bar – Notification 4.4 Settings The Settings menu allows configuration to the IKARPC-07A-A9, such as Wi-Fi, volume, screen brightness, etc. To enter the Settings menu, tap Settings on the launcher page. Page 36...

  • Page 49: Wireless & Networks

    IKARPC-07A-A9 In-vehicle Panel PC 4.4.1 WIRELESS & NETWORKS Figure 4-12: Wireless and Networks Settings In the WIRELESS & NETWORKS field, the user can turn on/off the Wi-Fi and Bluetooth functions, and configure the network settings.  Wi-Fi allows the user to turn on or turn off the Wi-Fi function. When the Wi-Fi function is turned on, tap this item to manage the access points.

  • Page 50: More Settings

    IKARPC-07A-A9 In-vehicle Panel PC 4.4.1.1 More Settings Figure 4-13: More Settings Menu After tapping More… in the WIRELESS & NETWORKS field, the user can configure the following network settings.  Airplane mode turns on or turns off the airplane mode.

  • Page 51: Sound

     Screen lock sound enables or disables playing a sound when unlocking the home screen.  Switch to HeadPhone allowing the user to play sounds through the headset connected to the audio line-out connector of the IKARPC-07A-A9. Page 39...

  • Page 52: Display

    IKARPC-07A-A9 In-vehicle Panel PC 4.4.3 Display Figure 4-15: Display Menu Use the Display menu to configure the following items.  Brightness adjusts the screen brightness.  Wallpaper sets up the wallpaper.  Sleep sets up the time of inactivity after which the screen turns to sleep mode.

  • Page 53: Storage

    IKARPC-07A-A9 In-vehicle Panel PC 4.4.4 Storage The Storage menu displays the status of the internal storage and the installed SD card, and allows users to manage the data stored in them. Figure 4-16: Storage Menu Page 41...

  • Page 54: Apps

    IKARPC-07A-A9 In-vehicle Panel PC 4.4.5 Apps The Apps menu displays the applications installed in the device, and allows users to manage them. Figure 4-17: Apps Menu 4.4.6 Users The Users menu allows the user to configure the owner information. Figure 4-18: Users Menu...

  • Page 55: Location Access

    IKARPC-07A-A9 In-vehicle Panel PC 4.4.7 Location Access Figure 4-19: Location Access Menu Use the Location access menu to configure the following items.  Access to my location lets apps obtain the user’s location information.  GPS satellites allows apps to use the GPS in the device to pinpoint the user’s location. This item is available only when the Access to my location item is enabled.

  • Page 56: Security

    IKARPC-07A-A9 In-vehicle Panel PC 4.4.8 Security Figure 4-20: Security Menu Use the Security menu to configure the following items.  Screen lock sets up the way to unlock the screen.  Owner info configures the owner information to display on the lock screen.

  • Page 57: Language & Input

    Figure 4-21: Language & Input Menu Use the Language & input menu to configure the following items.  Language sets up the language for IKARPC-07A-A9.  Spell checker allows the user to enable the spell checking function and configure its settings.

  • Page 58: Backup & Reset

    IKARPC-07A-A9 In-vehicle Panel PC 4.4.10 Backup & Reset Figure 4-22: Backup & Reset Menu Use the Back & reset menu to configure the following items.  Factory data reset erases all data from the internal storage of the IKARPC-07A-A9. Page 46...

  • Page 59: Add Account

    IKARPC-07A-A9 In-vehicle Panel PC 4.4.11 Add account Tap Add account to start setting up an e-mail or corporate account. Figure 4-23: Add Account Menu 4.4.12 Date & Time Figure 4-24: Date & Time Menu Page 47...

  • Page 60: Accessibility

    IKARPC-07A-A9 In-vehicle Panel PC Use the Date & time menu to configure the following items.  Automatic date & time uses the network-provided time.  Automatic time zone uses the network-provided time zone  Select time zone sets up the time zone.

  • Page 61: About Tablet

    IKARPC-07A-A9 In-vehicle Panel PC  Speak passwords allows the system to speak passwords.  Text-to-speech output configures the text-to-speech settings.  Touch & hold delay configures the touch & hold delay settings.  Enhance web accessibility allows apps to install scripts from Google that make their web content more accessible.

  • Page 62: File Management

    4.5 File Management The IKARPC-07A-A9 provides a file management tool that allows users to manage files in the internal storage and external storage devices. Tap ES File Explorer on the application page to launch it.

  • Page 63: Figure 4-28: Es File Explorer Screen

    The user can view all the possible storage devices, including  sdcard0: internal storage of the IKARPC-07A-A9  sdcard1: SD card connected to the IKARPC-07A-A9  usb1: USB storage device connected to the USB host connector on the side panel. Refer to Figure 1-5 for the connector location.

  • Page 64: Camera

    IKARPC-07A-A9 In-vehicle Panel PC 4.6 Camera The IKARPC-07A-A9 equips with a 5-megapixel front-facing auto-focus camera, and also accepts a video device through the video input connector on the rear panel. To manage the built-in camera or the connected video device, tap Camera on the Launcher page.

  • Page 65: System Update

    If choosing to update the OS or firmware from the SD card, save the update file Step 3: to an SD card and insert the SD card to the IKARPC-07A-A9 (see Section 3.4 for the SD card installation instruction). The user can also update from OTA (over-the-air) via Wi-Fi connection.

  • Page 66: Interface Connectors

    IKARPC-07A-A9 In-vehicle Panel PC Chapter Interface Connectors Page 54...

  • Page 67: Peripheral Interface Connectors

    IKARPC-07A-A9 In-vehicle Panel PC 5.1 Peripheral Interface Connectors The motherboard of the IKARPC-07A-A9 comes with a number of peripheral interface connectors and configuration jumpers. The connector locations are shown in Figure 5-1 and Figure 5-2. The Pin 1 locations of the on-board connectors are also indicated in the diagrams below.

  • Page 68: Internal Peripheral Connectors

    Internal peripheral connectors are found on the motherboard and are only accessible when the motherboard is outside of the chassis. The table below shows a list of the peripheral interface connectors on the IKARPC-07A-A9 motherboard. Pinouts of these connectors can be found in the following sections.

  • Page 69: Camera Connector (Camera1)

    IKARPC-07A-A9 In-vehicle Panel PC 5.2.1 Camera Connector (CAMERA1) PIN NO. DESCRIPTION PIN NO. DESCRIPTION CIM_AF2V8 CIM_nRST MIPI_D1_P I2C_SDA1 MIPI_D1_N I2C_SCL1 MIPI_CLK_P CAMERA_PWD MIPI_CLK_N CAMERA_MCLK MIPI_D0_P CIM_IO_1V5 MIPI_D0_N CIM_IO1V8 CIM_A2V8 Table 5-2: Camera Connector (CAMERA1) Pinouts 5.2.2 LED Connector (LED_BD2) PIN NO.

  • Page 70: Lvds Connector (Cn2)

    IKARPC-07A-A9 In-vehicle Panel PC 5.2.3 LVDS Connector (CN2) PIN NO. DESCRIPTION PIN NO. DESCRIPTION LCM_LEDA LCM_RIN3- LCM_LEDA VLCD_VGH LCM_CLK+ LCM_CLK- VLCD_VGL LCM_RIN2+ LCM_RIN2- VLCD_3V3 LCM_LEDK LCM_RIN1+ LCM_LEDK LCM_RIN1- VCC_LCD_AVDD LCM_RIN0+ LCM_RIN0- DIMO VLCD_3V3 LCM_nRST VLCD_3V3 VLCD_3V3 LCM_RIN3+ VLCD_VCOM Table 5-4: LVDS Connector (CN2) Pinouts 5.2.4 Microphone Connector (MIC1)

  • Page 71: Programming Connector (Mcu1)

    IKARPC-07A-A9 In-vehicle Panel PC 5.2.5 Programming Connector (MCU1) PIN NO. DESCRIPTION MCLR MCU_PWR ICSPCLK2 ICSPDAT2 Table 5-6: Programming Connector (MCU1) Pinouts 5.2.6 Programming Connector (JP2) PIN NO. DESCRIPTION MCLR#-1 5V_OBD 2580_CLK 2580_DAT Table 5-7: Programming Connector (JP2) Pinouts 5.2.7 Speaker Connector (SPK1) PIN NO.

  • Page 72: Table 5-9: Touch Panel Connector (Cn10) Pinouts

    IKARPC-07A-A9 In-vehicle Panel PC CTP_RST# I2C_SCL3 I2C_SDA3 CTP_INTR Table 5-9: Touch Panel Connector (CN10) Pinouts Page 60...

  • Page 73: A Regulatory Compliance

    IKARPC-07A-A9 In-vehicle Panel PC Appendix Regulatory Compliance Page 61...
  • Page 74 IKARPC-07A-A9 In-vehicle Panel PC DECLARATION OF CONFORMITY This equipment is in conformity with the following EU directives: EMC Directive (2004/108/EC, 2014/30/EU)  Low-Voltage Directive (2006/95/EC, 2014/35/EU)  RoHS II Directive (2011/65/EU, 2015/863/EU)  Ecodesign Directive 2009/125/EC  If the user modifies and/or install other devices in the equipment, the CE conformity declaration may no longer apply.
  • Page 75 IKARPC-07A-A9 In-vehicle Panel PC Español [Spanish] IEI Integration Corp declara que el equipo cumple con los requisitos esenciales y cualesquiera otras disposiciones aplicables o exigibles de la Directiva 2014/53/EU. Ελληνική [Greek] IEI Integration Corp ΔΗΛΩΝΕΙ ΟΤΙ ΕΞΟΠΛΙΣΜΟΣ ΣΥΜΜΟΡΦΩΝΕΤΑΙ ΠΡΟΣ ΤΙΣ...
  • Page 76 IKARPC-07A-A9 In-vehicle Panel PC Româna [Romanian] IEI Integration Corp declară că acest echipament este in conformitate cu cerinţele esenţiale şi cu celelalte prevederi relevante ale Directivei 2014/53/EU. Slovensko [Slovenian] IEI Integration Corp izjavlja, da je ta opreme v skladu z bistvenimi zahtevami in ostalimi relevantnimi določili direktive 2014/53/EU.
  • Page 77 IKARPC-07A-A9 In-vehicle Panel PC FCC WARNING This equipment complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: This device may not cause harmful interference, and  This device must accept any interference received, including interference ...
  • Page 78 IKARPC-07A-A9 In-vehicle Panel PC CHINA ROHS The label on the product indicates the estimated “Environmentally Friendly Use Period” (EFUP). This is an estimate of the number of years that these substances would “not leak undergo abrupt change.” This product contain replaceable sub-assemblies/components which have a shorter EFUP such as batteries and lamps.

  • Page 79: B Safety Precautions

    IKARPC-07A-A9 In-vehicle Panel PC Appendix Safety Precautions Page 67...

  • Page 80: Safety Precautions

     Electric shocks can occur if the IKARPC-07A-A9 chassis is opened when it is running. To avoid risk of electric shock, this device must only be connected to a supply mains with protective earth.

  • Page 81: Anti-Static Precautions

    Electrostatic discharge (ESD) can cause serious damage to electronic components, including the IKARPC-07A-A9. Dry climates are especially susceptible to ESD. It is therefore critical that whenever the IKARPC-07A-A9 is opened and any of the electrical components are handled, the following anti-static precautions are strictly adhered to.

  • Page 82: Product Disposal

    IKARPC-07A-A9 In-vehicle Panel PC B.1.3 Product Disposal CAUTION: Risk of explosion if battery is replaced by an incorrect type. Only certified engineers should replace the on-board battery. Dispose of used batteries according to instructions and local regulations.  Outside the European Union–If you wish to dispose of used electrical and electronic products outside the European Union, please contact your local authority so as to comply with the correct disposal method.

  • Page 83: Maintenance And Cleaning Precautions

    Some components in the IKARPC-07A-A9 may only be cleaned using a product specifically designed for the purpose. In such case, the product will be explicitly mentioned in the cleaning tips. Below is a list of items to use when cleaning the IKARPC-07A-A9. ...
  • Page 84 IKARPC-07A-A9 In-vehicle Panel PC  Water or rubbing alcohol–A cloth moistened with water or rubbing alcohol can be used to clean the device.  Using solvents–The use of solvents is not recommended when cleaning the device as they may damage the plastic parts.

  • Page 85: Cobd-Ii Reader Command

    IKARPC-07A-A9 In-vehicle Panel PC Appendix OBD-II Reader Command Page 73...

  • Page 86: Select A Chip Initial Mode: Update F/W Or Run F/W

    IKARPC-07A-A9 In-vehicle Panel PC C.1 Select a Chip Initial Mode: UpDate F/W or RUN F/W  AP sends query  F/W receives query Enter Boot Mode Enter RUN Mode C.2 Boot Mode  Launch AP: P1618QP (Pic18F Bootloader ) ...
  • Page 87 IKARPC-07A-A9 In-vehicle Panel PC F/W returns (after receiving query) Select a mode to send Tele mode response CAN S mode response Enter Tele mode to respond Enter CAN S mode to respond Page 75...

  • Page 88: Into Can_Standard V2.2.B (Can Standard)

    IKARPC-07A-A9 In-vehicle Panel PC C.4 Into CAN_Standard V2.2.B (CAN standard)  AP sends query  F/W receives query 0x0A 0x0D Sent by xxx Baud 0x00 Set CAN Reserved baud 0x00 TxIDE RTR ID(1 ID(2 ID(3 ID(4 Set to Reserved B0 B1...
  • Page 89 IKARPC-07A-A9 In-vehicle Panel PC complete 0x0A Menu setup complete TxID ID(1) ID(2) ID(3) ID(4) 0x0A Read query setup Read menu D(1) D(2) D(3) D(4) 1ID( 1ID( 1ID( 1ID( 2ID( 2ID( 2ID( 2ID( D(1) D(2) D(3) D(4) setup RxID 0x0A 1ID(...

  • Page 90: Into Telematics (Vehicel Information)

    IKARPC-07A-A9 In-vehicle Panel PC C.5 Into Telematics (Vehicel Information)  F/W:Telematics  AP: Telematics V1.005  AP sends query  F/W receives query Scan all Scan all Scan OBD-II Scan J1939 Scan FMS OBD-II input PID-1 OBD-II input PID-2 OBD-II...
  • Page 91 IKARPC-07A-A9 In-vehicle Panel PC Reserved J1939 input PSPF FMS input PSPF Version  F/W returns (after receiving query) device is scanned Devices Scanned Page 79...
  • Page 92 IKARPC-07A-A9 In-vehicle Panel PC OBD packet format (ASCII code) OBD packet has five different format, they are: 1. CAN 11bits 250 2. CAN 29bits 250 3. CAN 11bits 500 4. CAN 29bits 500 5.Scanning Each format has its input code, they are:...
  • Page 93 IKARPC-07A-A9 In-vehicle Panel PC Byte 4 define as A. (same with the PID code table on Wikipedia) Byte 5 define as B. (same with the PID code table on Wikipedia) Byte 6 define as C. (same with the PID code table on Wikipedia) Byte 7 define as D.

  • Page 94: D Watchdog Timer

    IKARPC-07A-A9 In-vehicle Panel PC Appendix Watchdog Timer Page 82...
  • Page 95 IKARPC-07A-A9 In-vehicle Panel PC NOTE: The following discussion applies to DOS. Contact IEI support or visit the IEI website for drivers for other operating systems. The Watchdog Timer is a hardware-based timer that attempts to restart the system when it stops working.
  • Page 96 IKARPC-07A-A9 In-vehicle Panel PC NOTE: The Watchdog Timer is activated through software. The software application that activates the Watchdog Timer must also deactivate it when closed. If the Watchdog Timer is not deactivated, the system will automatically restart after the Timer has finished its countdown.

  • Page 97: E Hazardous Materials Disclosure

    IKARPC-07A-A9 In-vehicle Panel PC Appendix Hazardous Materials Disclosure Page 85...
  • Page 98 IKARPC-07A-A9 In-vehicle Panel PC The details provided in this appendix are to ensure that the product is compliant with the Peoples Republic of China (China) RoHS standards. The table below acknowledges the presences of small quantities of certain materials in the product, and is applicable to China RoHS only.
  • Page 99 IKARPC-07A-A9 In-vehicle Panel PC 此附件旨在确保本产品符合中国 RoHS 标准。以下表格标示此产品中某有毒物质的含量符 合中国 RoHS 标准规定的限量要求。 本产品上会附有”环境友好使用期限”的标签，此期限是估算这些物质”不会有泄漏或突变”的 年限。本产品可能包含有较短的环境友好使用期限的可替换元件，像是电池或灯管，这些元 件将会单独标示出来。 部件名称 有毒有害物质或元素 铅 汞 镉 六价铬 多溴联苯 多溴二苯 醚 (Pb) (Hg) (Cd) (CR(VI)) (PBB) (PBDE) 壳体 显示 印刷电路板 金属螺帽 电缆组装 风扇组装 电力供应组装 电池 O: 表示该有毒有害物质在该部件所有物质材料中的含量均在 SJ/T 11363-2006 (现由 GB/T 26572-2011 取代) 标准规定的限量要求以下。...
