Lenze SMVector Installation And Operation Manual page 13

Code
No. Name
p441 Relay Output
TB-19, 20, 21
P144 Digital Output
Inversion
SMVector I/O Module ALSV01 v1.0 13376253
Possible Settings
Default Selection
0 0 None
1 Run
2 Reverse
3 Fault
4 Inverse Fault
5 Fault Lockout
6 At Speed
7 Above Preset Speed #6
8 Current Limit
9 Follower Loss (4-20 mA)
10 Loss of Load
11 Local Keypad Control Active
12 Terminal Strip Control Active
13 Remote Keypad Control Active
14 Network Control Active
15 Standard Reference Active
16 Auto Reference Active
17 Sleep Mode Active
18 PID Feedback < Min. Alarm
19 Inverse PID Feedback < Min. Alarm
20 PID Feedback > Max Alarm
21 Inverse PID Feedback > Max Alarm
22 PID Feedback within
Min/Max Alarm range
23 PID Feedback outside
Min/Max Alarm range
24 Reserved
25 Network Activated
26 Loss of 0-10V Input
27 Sequencer Controlled
28 Sequencer Active
29 Sequencer Suspended
30 Sequence Done
31 Output Frequency = 0.0Hz
Invert
P144
P441
0 NO
1 NO
2 NO
3 NO
4 YES
5 YES
6 YES
7 YES
NOTE
Inverting P140, P142 or P441 when the parameter is set to NONE (0) will result in the output being
energized continuously.
Commissioning
Disables the output
Energizes when the drive is running
Energizes when reverse rotation is active
De-energizes when the drive trips, or power is removed
Energizes when the drive trips
P110 = 3...6: De-energizes if all restart attempts fail
Energizes when output frequency = commanded frequency
Energizes when output frequency > P136
Energizes when motor current = P171
Energizes when 4-20 mA signal falls below 2 mA
Energizes when motor load drops below P145; Refer to
P146 also
Energizes when the selected source is active for start
control
Energizes when P101 reference is active
Energizes when Auto Reference is activated using TB-13
input; refer to P121...P124
Refer to P240...P242
Energizes when PID feedback signal < P214
De-energizes when PID feedback signal < P214
Energizes when PID feedback signal > P215
De-energizes when PID feedback signal > P215
Energizes when PID feedback signal is within the Min/Max
Alarm range; refer to P214, P215
Energizes when PID feedback signal is outside the Min/Max
Alarm range; refer to P214, P215
Requires 15HP (11kW) or higher drive.
No function for 0.33-10HP (0.25kW-7.5kW) drives.
Energizes when 0-10V signal < P158
State set in individual sequencer segments
End sequence
Output inactive
Used to invert the selections for P140, P441 (Relay Output)
Invert Invert
and P142 (TB-14 Output).
P142 P140
NO NO EXAMPLE: When P140 = 6 (AT SPEED), the relay is
NO YES
energized when output frequency = commanded
YES NO
frequency. IF P144=1, 3, 5 or 7, then P140 is inverted
YES YES
(INVERSE AT SPEED) and the relay is energized when the
NO NO
output frequency does not equal the command frequency.
NO YES
YES NO
YES YES
13
IMPORTANT
