4.2

Additional I/O Module Parameters

In addition to the parameters detailed in the SMVector Frequency Inverter Operating Instructions (SV01),
installing the Additional I/O Module provides access to supplementary parameters exclusive to the Additional
I/O Module. Table 4 lists these supplementary parameters.
Code
No. Name
TB-13F Input
P426
Function
TB-13G Input
p427
Function
WARNING!
Jog overrides all STOP commands! To stop the drive while in Jog mode, the Jog input must be deactivated or a fault condition induced.
NOTE
• When input is activated, settings 1...7 override P101
• When TB-13A to TB-13D; TB-13F and TB-13G are confi gured for Auto References other than MOP, TB-13G overrides TB-13F, TB-13F
overrides TB-13D, TB-13D overrides TB-13C, TB-13C overrides TB-13B and TB-13B overrides TB-13A. Any other Auto Reference will
have priority over MOP.
• Settings 10...14 are only valid in Terminal Strip mode (P100 = 1, 4, 5, 6)
• If Start/Run/Jog Forward and Start/Run/Jog Reverse are both activated, drive will STOP
• If Jog input is activated while the drive is running, the drive will enter Jog mode; when Jog input is deactivated, drive will STOP
• An F.AL fault will occur if the Assertion Level switch (ALsw) position does not match the P120 setting and any of the digital inputs
(P121...P124, P426 ... P427) are set to a value other than 0.
• An F.IL fault will occur under the following conditions:
- TB-13A...TB-13D and TB-13F...TB-13G settings are duplicated (each setting, except 0 and 3, can only be used once)
- One input is set to "MOP Up" and another is not set to "MOP Down", or vice-versa.
- One input is set to 10 and another input is set to 11...14.
- One input is set to 11 or 12 and another input is set for 13 or 14.
• TB-13D and P124 exist in 15HP (11kW) and greater drives only
SMVector I/O Module ALSV01 v1.0 13376253
Commissioning
Table 4: Additional I/O Module Parameters
Possible Settings
Default Selection
0 None
0
1 AUTO Reference: 0-10 VDC
2 AUTO Reference: 4-20 mA
RESERVED
4 AUTO Reference: MOP Up
5 AUTO Reference: MOP Down
6 AUTO Reference: Keypad
7 AUTO Reference: Network
8 Control Select
9 Network Enable
10 Reverse Rotation
11 Start Forward
12 Start Reverse
13 Run Forward
14 Run Reverse
15 Jog Forward
16 Jog Reverse
17 Accel/Decel #2
18 DC Brake
19 Auxiliary Ramp to Stop
20 Clear Fault
21 External Fault F.EF
22 Inverse External Fault F.EF
Disables input
For frequency mode, see P160...P161,
For PID mode, see P204...P205,
For vector torque mode, see P330
• Normally open: Close input to increase or decrease
speed, PID setpoint or torque setpoint.
• MOP Up is not active while in STOP
Use when P100 = 4, 5 to switch between terminal strip
control and local or remote keypad control.
Required to start the drive through the network.
Open = Forward
Refer to Note for typical circuit
Refer to Note for typical circuit
Jog Forward speed = P134
Jog Reverse speed = P135
Active even if P112 = 0
Refer to P125, P126
Refer to P174; close input to override P175
Normally closed: Opening input will ramp drive to STOP
according to P127, even if P111 is set to Coast (0 or 1).
Close to reset fault
Normally closed circuit; open to trip
Normally open circuit; close to trip
12
IMPORTANT
Closed = Reverse
