4

Commissioning

4.1

Network Parameters (P400)

Code
No. Name
Network Protocol
p400
Module Type
p401
Installed
Module Status
P402
Module Reset
P403
Module Timeout
P404
Action
Current Network
P405
Fault
Proprietary
P406
p407 ... P499
NOTE
Set P400 = 8 for the SMVector drive to communicate with the additional I/O module.
SMVector I/O Module ALSV01 v1.0 13376253
Possible Settings
Default Selection
0 Not Active
1 Remote Keypad
2 Modbus RTU
3 CANopen
4 DeviceNet
5 Ethernet
6 Profi bus
7 Lecom-B
8 I/O Module
0 No Module Installed
0
1 Basic I/O (0x0100, 1.0.0)
2 RS485/Rem. Keypad (0x0200, 2.0.0)
3 CANopen (0x0300, 3.0.0)
11 PROFIBUS (0x1100, 11.0.0)
12 Ethernet (0x1200, 12.0.0)
0 Not Initialized
0
1 Initialization: Module to EPM
2 Initialization: EPM to Module
3 Online
4 Failed Initialization Error
5 Time-out Error
6 Initialization Failed
7 Initialization Error
0 0 No Action
1 Reset parameters to default values
0 No Fault
0
1 STOP (see P111)
2 Quick Stop
3 Fault (F_ntF)
0 No Fault
1 F.nF1
2 F.nF2
3 F.nF3
4 F.nF4
5 F.nF5
6 F.nF6
7 F.nF7
Module Specifi c Parameters
Commissioning
This parameter setting is based upon the network
or I/O module that is installed.
Module type format: 0xAABC; Drive Display: AA.B.C
AA = Module Type
B = Major revision
C = minor revision
Module type mismatch P401
Protocol selection mismatch P400
Returns module parameters 401...499 to
the default values shown in the manual
Action to be taken in the event of a
Module/Drive Time-out.
Time is fi xed at 200ms
STOP is by the method selected in P111.
NetIdle Mode
Loss of Ethernet I/O connection
Network Fault
Explicit Message Timeout
Overall Network Timeout
Overall Explicit Timeout
Overall I/O Message Timeout
Manufacturer specifi c
Refer to the Communications Reference Guide
specifi c to the network or I/O module installed.
11
IMPORTANT
