5. Measuring Percent Outdoor Air
Display
1.
2.
3.
4.
5.
1.
2.
3.
4.
5.
1.
2.
3.
4.
5.
<DATA STORAGE>
key to select "4.DATA STORAGE ?", and press
Use
key.
key to select "YES" or "NO" for data storage, and press
Use
key.
<To save the settings>
key to select "5.SET TO START", and press
Use
* If pressing
key before completing the settings, you will return to
the MENU screen without that the changes are saved.
<Standby Screen>
This is a standby screen before a measurement starts.
Press
key to start measuring.
Display Icons:
1. RDY.: Current Status (READY/SAMPLE)
2. N 1: Current number of data measured
3. / 50:
Total number of data to be measured according to
the setting.
4. TMP.: Indicates that temperature value will be read to
perform calculations.
Mode is selected, "CO2" will be displayed.)
(When CO
2
5. R_A: Displays what measuring point will be used.
(R_A: Return Air, S_A: Supply Air, O_A: Outdoor Air.).
<While Measuring>
Press
key to pause measuring, and press
* You can stop measuring by pressing
data will not be saved.
<Waiting for the next measurement point>
After Return Air (R_A) measurement is completed, "NEXT" will show
up at the top to indicate that it is waiting for the next Supply Air (S_A)
measurement to be started.
After that, Supply Air (S_A) measurement and Outdoor Air (O_A)
measurement will be performed respectively.
Procedure
key again to resume.
key. However, any measured
16
key.
