Festo MS6-SV-...-C series Operating Instructions

Soft-start/quick exhaust valve
MS6(N)-SV-...-C
Operating instructions
(Translation of the original instructions)
Soft-start/quick exhaust valve MS6(N)-SV-...-C
1 About this document
This document describes the use of the above-mentioned product.
The document contains additional information for use of the product in
safety-related systems (safety handbook in accordance with IEC 61508).
1.1 Further applicable documentation
– Assembly instructions for cover (tamper protection) MS6/9-SV-C-MK/MH
For all available product documentation è www.festo.com/pk
1.2 Target group
The document is targeted towards persons who assemble and operate
the product. It is additionally targeted towards individuals who are entrusted with
the planning and application of the product in a safety-related system.
1.3 Specified standards
Version status
IEC 61508-2:2010-04
EN 60204-1:2006-06/A1:2009-02 + AC:2010-02
EN ISO 4414:2010-11
Fig. 1 Standards
2 Safety
2.1 Safety instructions
– Only use the product in its original condition without unauthorised modifications.
– Only use compressed air as an operating medium in accordance with the spe­
cification è 13 Technical data.
2.2 Intended use
The product is intended for installation in machines or automated systems and
may be used only in the following ways:
– in an industrial environment
– in its original condition, without unauthorised modifications
– in safety-related systems, only with cover (tamper protection) MS6-...-MK
– in perfect technical condition
2.3 Foreseeable misuse
Foreseeable misuse includes:
– use outdoors
– bypassing of safety functions
– use in reversible operation (using supply air instead of exhaust air, and vice
versa)
– use in low demand mode in accordance with EN 61511
– vacuum operation
2.4 Training of specialized personnel
Installation, mounting, commissioning, maintenance, repair and removal from
operation may only be performed by qualified specialized personnel with know­
ledge of and experience with electrical and pneumatic control technology.
Festo AG & Co. KG
Ruiter Straße 82
73734 Esslingen
Germany
+49 711 347-0
www.festo.com
8084750
2018-02c
[8084752]
. . . . . . . . . . . . . . . . . . . . . English
EN ISO 13849-1:2015-12
EN ISO 13849-2:2012-10
EN 1037/A1:2008-04
2.5 Further information
Accessories è www.festo.com/catalogue
Designation
Silencer
1)
Cover (tamper protection)
For covering setting and control elements
1)
Fig. 2 Accessories
2.6 Service
Contact your regional Festo contact person if you have technical questions
è www.festo.com.
3 Information on functional safety
3.1 Attainable safety rating
The product is suitable for use as an element in a safety-related system in accord­
ance with EN ISO 13849-1 up to category 1, performance level (PL) c.
Note
The suitability for certain applications can only be determined in connection with
the assessment of further components of the subsystem.
3.2 Safety functions
The safety functions are:
– safe venting in the downstream piping system and terminals
– prevention of unexpected start-up (pressurisation)
The safety functions are triggered by switching off the power supply at the pilot
solenoid valve. As long as the voltage at the pilot solenoid valve remains switched
off, the connection between ports 2 and 3 is enabled è Fig. 5.
This switching position represents the safe state.
3.3 Operating conditions
– General notes on safe operation è 2 Safety.
– Ambient conditions and additional technical specifications è 13 Technical data.
Note
• Actuate the product at least once per month to ensure the safety function
works properly.
3.4 Limitations of use
The duration of use is limited to the maximum operating time T
è Fig. 3.
than the mission time T
M
3.5 Characteristic values
Safety characteristic
(in accordance with IEC 61508)
Safety function
(Safety Function)
1)
Note on forced checking procedure
Performance level (PL) in accordance with EN ISO
13849-1
Service life value
Mission time
Maximum operating time
Diagnostic coverage
(Diagnostic Coverage)
Hardware fault tolerance
(Hardware Fault Tolerance)
Element type in accordance with EN 61508-2
Average probability of dangerous
failure per hour
(Average probability of dangerous
failure per hour)
Max. positive test pulse with logic 0
Max. negative test pulse with logic 1
Exhaust time
CE marking (see declaration of conformity)
è www.festo.com/sp
1) Use in low demand mode is not permissible.
2) Applies up to the average number of operations per year (n
Fig. 3 Safety characteristics
Type
U-¾-B
MS6-SV-C-MK
or is no more
10d
Value
MS6(N)-SV-...-C
-10V24 -V24 -V110
-10V24P -V24P
-10V24C
-10V24D
Exhausting
Prevention of unexpected start-up
(pressurisation) in accordance with
EN 1037/A1
Switching frequency at least 1/month
2)
Up to category 1, PL c
B 1.2 million switching cycles
10
T [a] 20
M
T [a] 2 x B /n or max. T
10d 10 op M
DC 0
HFT 0
Type A
è Fig. 4
PFH
d
[μs] 1000 2000 –
[μs] 800 1900 –
è Fig. 15
[s]
In accordance with EU Machinery Directive
– In accordance with
Low Voltage
Directive
) = 630,000
op
-V230
–
–
