3-4 I M
NSTALLING THE
Setting DIP
Switches

DIP Switch Features

Setting the DIP
Switches
ODULE
If you are using a management module and do not plan to use the DIP
configuration command, skip this section and go to the section
Installing the Module
The CoreBuilder 5000 Ethernet 12-Port 100BASE-TX Workgroup
FastModule has an 8-position DIP switch. All of the DIP switch settings
on the 12-Port 100BASE-TX Workgroup FastModule are ignored if an
appropriate CoreBuilder 5000 network management module (for
example, DMM Version v4.10 or later) is already installed in the hub.
Use network management commands, rather than the DIP switches, to
configure the module.
This section describes:
DIP Switch Features

Setting the DIP Switches

DIP Switch Definition
Use the DIP switch to:
Select a network for all ports on the 12-port 100BASE-TX
Workgroup FastModule
Choose the primary module configuration:
Non-volatile RAM configuration (software configuration)
DIP segment selection (DIP-specified module configuration)
To set the module to access the DIP switch settings when using a
management module, issue the SET DEVICE DIP_CONFIGURATION
command from the management module.
If you do not have a CoreBuilder 5000 Distributed Management
Module installed in your hub, your hub configuration defaults to the
DIP switch settings on the module.
in this chapter.
