2-2 D Y N
ESIGNING OUR
Network
Configuration Rules
ETWORK
This section describes general rules for configuring a Fast Ethernet
network using twisted pair as the horizontal medium (connection to
printers, computers). It also provides rules to ensure that your network
configuration conforms to distance limitations imposed by Ethernet and
networking equipment.
The following topics are discussed:

Before Configuring Your Network

Basic Network Rules
Network Backplane Restrictions
Before Configuring Your Network
Before you configure your network, consider your:
Plans for expansion – If the network expands beyond a certain
size, you may need to add additional internetworking devices.
Maximum cable length – Cabling requirements include:
100 Ohm 2-pair Category 5 UTP for up to 100 meters (328 feet)
100 Ohm STP for up to 100 meters (328 feet)
Management access – For in-band management through the
DMM, SNMP and TELNET require another type of Downlink
Fastmodule, SwitchModule, or 10BASE-T Ethernet module and
network monitor card installed in the hub.
Out-of-band management requires Serial Line Interface
Protocol (SLIP) (includes SNMP, TELNET) and Direct Asynchronous
terminals.
