Quick Installation

Table 3-1 outlines the steps for the installation of your module. If you
are familiar with installing CoreBuilder 5000 modules, use this table as
a checklist. Otherwise, consult the remainder of this chapter.
Table 3-1 Quick Installation Checklist
Step Procedure
1 Verify that your network complies with the
basic rules for network design.
2 Unpack the module.
3 Configure the DIP switch settings. If you
have a network management module
installed in the hub, configure the module
using the management commands described
later in this chapter.
4 Enter the SHOW POWER
command line of the terminal. This
command displays current power
requirements for the hub.
5 Insert a 12-Port 100BASE-TX Workgroup
Fastmodule into one open slot in the hub.
Fasten the ejectors and tighten the faceplate
screws.
6 Establish connections from the 12-port
100BASE-TX Workgroup Fastmodule to
devices using the appropriate connectors and
cabling.
7 Verify LED status for normal operation.
1
Refer to the CoreBuilder 5000 Integrated System Hub Installation and Operation Guide for
details on hub power requirements.
For information about potential problems, consult the troubleshooting
techniques in Chapter
1
command at the
5.
Quick Installation 3-3
Chapter/Section
Designing
Chapter 2,
Your Network
Unpacking
Chapter 3,
Procedures
Setting DIP
Chapter 3,
Switches
Installing
Chapter 3,
the Module
Installing
Chapter 3,
the Module
Installing
Chapter 3,
the Module
Verifying
Chapter 4,
LED and Network
Operation
