Making Network
Connections
Sample
100BASE-TX
Workgroup
FastModule
Configuration
Table 2-2 summarizes the possible schemes for connecting
100BASE-TX Workgroup FastModules in your network.
Table 2-2 Network Connections
To connect a Use this type of
hub to a connector
Node RJ-45 port
100BASE-TX
Hub 100BASE-TX
Switch
FastModule using
RJ-45 connectors
The maximum allowable distance between the hub and a PC, server,
or other devices is 100 meters of Category 5 UTP cable. The UTP cable
used for hub-to-node connections is a straight-through connection. No
crossovers should be present.
Figure 2-1 shows a sample network configuration that implements
100BASE-TX Workgroup FastModules and CoreBuilder 5000 Switching
FastModules in the CoreBuilder 5000 hub.
A typical configuration for the 100BASE-TX Workgroup FastModule is
when you have a CoreBuilder 5000 7-slot hub running several 12-port
100BASE-TX Workgroup FastModules with a 100BASE-TX/FX
FastModule for a Fast Ethernet downlink connection over the
backplane.

Making Network Connections

...And this type
of cabling Purpose
Straight-through Connects PCs,
UTP servers, and
other network
devices directly
Straight-through
connected to the
UTP
hub.
Category 5 Connects
crossover UTP cable another hub.
When you make
this connection,
you must
connect to the
front panel TX
port on a 7-port
100BASE-FX/TX
FastModule.
2-7
