1-2
I
NTRODUCTION
12-Port 100BASE-TX
Workgroup
FastModule
Figure 1-1
illustrates the front panel of the 12-Port 100BASE-TX
Workgroup FastModule.
Figure 1-1
CoreBuilder 5000 12-Port 100BASE-TX Workgroup FastModule
Front Panel
Module status LED
Port status LEDs
RJ45 connectors
(ports 1 to 4)
RJ45 connectors
(ports 5 to 8)
RJ45 connectors
(ports 9 to 12)
6512M-TX
