3-2 I M
NSTALLING THE
Unpacking
Procedures
ODULE
Use one of the following proper grounding techniques when you install
the 12-Port 100BASE-TX Workgroup FastModule:
Use a foot strap and grounded mat or wear a grounded static
discharge wrist strap.
Touch the grounded rack or other source of ground just before you
handle the module and I/O cards.
CAUTION: Although the LEDs used in this product meet the
regulatory requirements for casual exposure to the eye, as with any
source of bright light, it is advised that one does not look into the light
source.
To unpack the 12-Port 100BASE-TX Workgroup FastModule:
1 Verify that the 12-Port 100BASE-TX Workgroup FastModule (Model
Number 6512M-TX) is the model you ordered by checking the model
number listed on the side of the shipping carton.
2 Note that the product model number printed on the shipping box
differs from the model number on the product. The model number on
the shipping box contains the prefix '3C9'.
3 Remove the 12-Port 100BASE-TX Workgroup FastModule, in its
antistatic bag, from the shipping carton.
4 Remove the module from the antistatic shielding bag and inspect it for
damage.
Always handle the 12-Port 100BASE-TX Workgroup FastModule by the
faceplate, being careful not to touch the components. If the module
appears to be damaged, return it to the antistatic shielding bag, repack
it in the shipping carton, and contact your local supplier.
Keep the shipping carton and antistatic shielding bag in which your
module was shipped for future storage or shipment.
5 Record the serial number of your 12-Port 100BASE-TX Workgroup
FastModule. The Hub Planning Chart, located in the CoreBuilder 5000
reference binder, and the Module Planning Chart supplied with your
module are provided for this purpose.
