Accessories

6.7 Adjustable Pipe Adapter

The adjustable pipe adapter accessory (XXXTXXAPA) can be permanently placed on a surface and
aimed in any direction within a 45° radius. The accessory kit includes two mounting flanges, a circular
pipe adapter, a 2" pipe nipple, a mounting flange for sighting tube, and all necessary bolts and washers.
sighting tube (XXXTXXMST)

6.8 ThermoJacket

The ThermoJacket
cast aluminum housing completely encloses the sensor and provides water cooling as well as air
purging. Sensing heads can easily be installed or removed with the ThermoJacket housing in its
mounted position.
32
info@Raytek-Direct.com
Figure 25: Pipe Adapter
Mounting flange for
Figure 26: Adjustable Pipe Adapter
® allows use of the sensor in ambient temperatures up to 315°C (600°F). The rugged
2x Mounting flange
(XXXTXXMF)
Rev. O7 07/2017
TX
