Snap Disk 30Sa Specifications - Overland Storage SnapServer 110 Configuration And Hardware Options Manual

Chapter 4 SnapServer and Expansion Array Hardware Specifications

Snap Disk 30SA Specifications

Feature
Network Connection
Dimensions
Power
Operating
Environment
Nonoperating
Environment
Regulatory
Certifications
52 Configuration and Hardware Options Guide
Specification
Fibre channel connection to SnapServer 15000 and 18000 only.
No direct network connection.
Width .....................16.5 in (419 mm)
Depth .....................22.5 in (571 mm)
Height ....................5.25 in (133.3 mm), 3U
Weight ...................88 lbs (40kg)
Power Rating: 450W, 100-240 VAC, 50-60Hz,
Input Current: 4.0A (Peak) for 115VAC, 2.0A (Peak) for 230VAC
Power Consumption: 210W (steady state), 445W (maximum)
Heat Dissipation: 716 BTUs/hr
41° F to 104° F (5° C to 40° C)
8% to 80% humidity (noncondensing)
Vibration: .21G at 5-500Hz Random for 120 min. max duration
Shock: 6 pulses of 5G for up to 10ms
Altitude: 0 ft. to 10,000 ft. (0 m to 3,048 m)
33.8° F to 122° F (1° C to 50° C)
8% to 80% humidity (condensing)
Vibration: 1.04G at 2-200Hz for 90 min. max duration
Altitude: 0 ft. to 35,000 ft. (0 m to 10,668 m)
UL, cUL, CE, FCC Class A, TuV, NEMKO
