Continuous Test - Megger DLRO10HD User Manual

Continuous Test

AUTO
3s
Tip: Use Clamp test leads (optional accessory).
TEST
1. Press .
Test starts (LED shows red).
Arrow direction animated (based on current direction)
and plateau.
2. Continuous measurements are taken on the connected
test piece.
Tests are made every three seconds.
Last test record is shown while the next test is in
progress.
3. DLROHD10X only: Save test results (if required).
At any point press
sound).
Test results are saved until the test is stopped or the
memory is full (2000 records).
TEST
4. Press to stop the test.
DLROHD10X only: If
results are saved and the memory slot number is shown.
The Save screen is shown for three seconds.
5. DLROHD10X only: If
save test results if required.
Press . The last complete test result is saved and its
memory slot number is shown.
The Save screen is shown for three seconds.
www.megger.com
1mA
10mA
µA
25 100
100 2.5
250
Ω
mA
Ω
Ω
2.5 250
kΩ mΩ
1A
25
mΩ
2.5
10A
mΩ
2.5
Ω
1A
250
mΩ
10A
(acknowledged by a beep
was pressed in Step 3, Test
was not pressed in Step 3,
DLRO10HD and DLRO10HDX
Tests
TEST
1 7
