Tests

Manual Bi-directional Test

AUTO
3s
Tip: Use Clamp test leads (optional accessory).
Note: In Manual test mode both the Current and Voltage test leads must be connected across the test piece
TEST
before is pressed.
TEST
1. Press (acknowledged by a beep sound).
Test starts (LED shows red).
Arrow direction animated (based on current direction)
and plateau.
Test result for the currently connected test piece is
shown.
2. DLRO10HDX only: Save test results (if required).
Press . The test result is saved and the memory slot
number is shown.
The Save screen is shown for three seconds.
3. If the test piece is still connected, press
another test.
4. DLRO10HDX only: Press
DLRO10HD and DLRO10HDX
14
1mA
10mA
µA
25 100
100 2.5
250
Ω
mA
Ω
Ω
2.5 250
kΩ mΩ
1A
25
mΩ
2.5
10A
mΩ
2.5
Ω
1A
250
mΩ
10A
TEST
to do
as required.
TEST
