Display Icons
DLRO10HDX
15
DLRO10HD
15
14
13
Item Description
1
Delete
2
Test Result Download mode
3
Recall Test Result Mode
4
Date and Time mode
5
Save mode
6
USB connected
7
Mains Power connected
8
Battery Status
Secondary Display
Directional arrow to show current flow above C indicator
Directional arrow to show current flow above P indicator
www.megger.com
1
2
3
4
5
14
13
6
7
8
9
10
12
11
7
8
10
9
11
12
Item Description
9
Noise (over 100 mV 50 / 60 Hz)
10
Over Temperature
11
Refer to User Guide
12
High Voltage Warning
13
Secondary Display
14
Primary Display
15
Direction of Current flow in a test
DLRO10HD and DLRO10HDX
Overview
