Comms Settings - ComAp IG-NT Reference Manual

Force value possibility: Yes
ConvCoefPulse
This setpoint adjusts the rate of increasing of the PulseCounter1 (integrating internal counters that can be
seen at PulseCounter1). The setpoint assigns number of pulses (BI:PulseCounter1) to increase the
PulseCounter integrating value by 1.
Step: 1/X
Range: 1 – 65000 1/X
Example:
Number of pulses on the physical input BI: PulseCounter1: 10
ConvCoefPulse1 = 2
Value of the PulseCounter1 integrating counter: 5
ConvCoefPulse1 - 4
This setpoint adjusts the rate of increasing of the PulseCounter1 – 4 (integrating internal counters that can
be seen at PulseCounter2-4). The setpoint assigns number of pulses
PulseCounter integrating value by 1.
Step: 1/X
Range: 1 – 65000 1/X
Example:
Number of pulses on the physical input BI: PulseCounter1: 10
ConvCoefPulse1 = 2
Value of the PulseCounter1 integrating counter: 5

Comms settings

Gen-set name
User-defined name, used for controller identification at remote connections. Gen-set name is max 15
characters long and has to be entered using PC software.
Hint:
The setpoint can be changed using PC SW only (e.g. InteliMonitor). Gen-set name isn't affected by
GenConfig SW.
Contr. addr
Controller CAN bus and RS-485 identification number. Each controller in the group has to have its own
unique number.
Step: 1
Range: 1 to 32
Hint:
When opening Direct or Modem connection to the controller (using PC monitoring/control SW), the Contr.
address has to correspond to the Gen-set setting in PC SW.
RS232(1) mode
Communication protocol selection for RS232(1) line.
DIRECT: Connection to a local PC running InteliMonitor. RS232 or RS485 (with internal or
external converter) lines can be used. Set this also for IG-IB connected via RS232 line.
MODEM (HW): Analog/GSM/ISDN modem connection. Select this for standard modems with HW flow
control. If selected and no CTS signal is detected, communication may not work
correctly.
MODEM (SW): Analog/GSM/ISDN modem connection. Select this for modems without HW flow control
– controller will use SW flow control signals XOn, Xoff, so only TxD and RxD signals
need to be connected between the controller and the modem.
