Comms Settings - ComAp intelilite nt amf20 Reference Manual

CT Location
Current CT´s are physically placed on GenSet (typically before GCB).
GenSet:
Current CT´s are physically placed on Load (typically between GCB and MCB).
Load:
Hint:
More details about this function is introduced in chapter

Comms Settings

ControllerAddr (1 .. 32)
Controller identification number. It is possible to set controller address different from the default value
(1) so that more IL controllers can be interconnected (via RS485) and accessed e.g. from Modbus
terminal.
Hint:
When opening connection to the controller it's address has to correspond with the setting in PC tool.
From LiteEdit it is only possible to connect to controllers with address 1.
COM1 Mode
Communication protocol switch for the COM1 channel.
DIRECT: LiteEdit communication protocol via direct cable.
MODEM: LiteEdit communication protocol via modem.
MODBUS: Modbus protocol. See detailed description in InteliCommunication guide.
ECU LINK: Protocol for communication with Cummins engines via Modbus.
Hint:
For details on communication speed and other technical parameters please see chapter
Data.
For detail description see chapter
register oriented Modbus.
COM2 Mode
Communication protocol switch for the COM2 channel, if dual communication module is plugged in.
DIRECT: LiteEdit communication protocol via direct cable.
MODBUS: Modbus protocol. See detailed description in InteliCommunication guide.
ECU LINK: Protocol for communication with Cummins engines via Modbus.
Hint:
For details on communication speed and other technical parameters please see chapter
Data.
For detail description see chapter
register oriented Modbus.
Hint:
Modbus TCP protocol using IB-Lite communication module requires setting
and COM2 Mode = MODBUS.
ModemIniString
If your modem needs some additional initialization AT commands (i.e. because of national telephony
network differences), it can be entered here. Otherwise leave this setpoint blank.
ModbusComSpeed
If the Modbus mode is selected on COM1 or COM2 channels, the Modbus communication speed in
bps can be adjusted here.
NT
– AMF20/25, SW version 2.2, ©ComAp – September 2014
InteliLite
IL-NT-AMF-2.2-Reference Guide.pdf
[GenSet/Load]
CT Location.
[-]
[DIRECT/MODEM/MODBUS/ECU LINK]
Modbus protocol. Since IL-NT version 1.3 controller supports
[DIRECT/MODBUS/ECU LINK]
Modbus protocol. Since IL-NT version 1.3 controller supports
[9600,19200, 38400, 57600]
Technical
Technical
COM1 Mode = DIRECT
70
