InteliMonitor

Functions
•
On-line direct, Modem or Internet single or multiple engine monitoring
•
Active Modem or Internet call from the controller to PC (activated by selected Alarm)
•
On-line or Off-line History record listing
•
Setpoints listing and adjusting (password protected)
•
Statistics value (e.g. Running hours) Set/Reset
•
Password and Access code change
Modbus protocol
Standard protocol enables receive/transmit any data or command from a Master system:
•
Direct connection: RS232, RS422, RS485
•
Modem connection
•
9600, 19200, 38400 or 57600 bps, 8 data bits, 1 stop bit, no parity
•
Transfer mode RTU
•
Function 3 (Read Multiply Registers)
•
Function 6 (Write Single Register)
•
Function 16 (Write Multiply Registers)
•
The response to an incoming message depends on the communication speed. The delay is not shorter
than the time needed to send/receive 3 and ½ characters.
The complete description of Modbus communication protocol can be found in Modbus Protocol Reference
Guide PI-MBUS-300 and Open Modbus Specification Release 1.0. Both documents are available from web
site at http://www.modicon.com/openmbus/
Hint:
Detail Modbus command description see in ComAp InteliCommunication guide.
Value and setpoint codes
Hint:
It is possible to export actual values, setpoints and history file on-line from the controller or off-line from the
archive using InteliMonitor – Monitor – Export data... function.
Technical data
Hint:
Technical data of the controller and extension modules find in the IGS-NT-Installation guide-x.y.pdf.
Language support
IG-NT in firmware version 1.4 supports following language code pages:
Code page Language
West European languages Windows 1252
0
134 Chinese
162 Turkish
129 Korean
204 Russian
238 East European languages
Inteli NT SPtM, SW Version 2.4, ©ComAp –December 2009
IGS-NT-SPtM-2.4-Reference Guide.PDF
.
Windows code
GB 2312
Windows 1254
Windows 1258
Windows 1251
Windows 1250
106
