Declaration of Conformity
Invertek Drives Limited
Offas Dyke Business Park
Welshpool
Powys, UK
SY21 8JF
Invertek Drives Ltd hereby states that the Optidrive ODP-2 product range conforms to the relevant safety provisions of the following council
directives:
2014/30/EU (EMC) and 2014/35/EU (LVD)
Design and manufacture is in accordance with the following harmonised European standards:
EN 61800-5-1: 2007
EN 61800-3 2 nd Ed: 2004
EN 55011: 2007
EN60529 : 1992
Safe Torque Off ("STO") Function
Optidrive P2 incorporates a hardware "Safe Torque Off" Function, designed in accordance with the standards listed below.
Standard
EN 61800-5-2:2007
EN ISO 13849-1:2006
EN 61508 (Part 1 to 7)
EN60204-1
EN 62061
*Note: TUV Approval of the "STO" function is relevant for drives which have a TUV logo applied on the drive rating label.
Electromagnetic Compatibility
All Optidrive P2 drives are designed with high standards of EMC in mind. All versions suitable for operation on Single Phase 230 volt and Three
Phase 400 volt supplies and intended for use within the European Union are fitted with an internal EMC filter. This EMC filter is designed to
reduce the conducted emissions back into the supply via the power cables for compliance with harmonised European standards.
It is the responsibility of the installer to ensure that the equipment or system into which the product is incorporated complies with the EMC
legislation of the country of use. Within the European Union, equipment into which this product is incorporated must comply with the EMC
Directive 2004/108/EC. When using an Optidrive P2 with an internal or optional external filter, compliance with the following EMC Categories,
as defined by EN61800-3:2004 can be achieved:
Drive Type / Rating
1 Phase, 230 Volt Input
ODL-2-x2xxx-xxBxx
3 Phase, 400 Volt Input
ODL-2-x4xxx-xxAxx
Compliance with EMC standards is dependent on a number of factors including the environment in which the drive is installed,
motor switching frequency, motor, cable lengths and installation methods adopted.
For motor cable lengths greater than 100m, an output dv / dt filter must be used, please refer to the Invertek Stock Drives
Note
Catalogue for further details
Vector Speed mode may not operate correctly with long motor cables and output filters. It is recommended to operate in V/F mode
for cable lengths exceeding 50m
All rights reserved. No part of this User Guide may be reproduced or transmitted in any form or by any means, electrical or mechanical
including photocopying, recording or by any information storage or retrieval system without permission in writing from the publisher.
Copyright Invertek Drives Ltd © 2016
All Invertek Optidrive P2 units carry a 2 year warranty against manufacturing defects from the date of manufacture. The manufacturer accepts
no liability for any damage caused during or resulting from transport, receipt of delivery, installation or commissioning. The manufacturer also
accepts no liability for damage or consequences resulting from inappropriate, negligent or incorrect installation, incorrect adjustment of the
operating parameters of the drive, incorrect matching of the drive to the motor, incorrect installation, unacceptable dust, moisture, corrosive
substances, excessive vibration or ambient temperatures outside of the design specification.
The local distributor may offer different terms and conditions at their discretion, and in all cases concerning warranty, the local distributor
should be contacted first.
This user guide is the "original instructions" document. All non-English versions are translations of the "original instructions".
The contents of this User Guide are believed to be correct at the time of printing. In the interest of a commitment to a policy of continuous
improvement, the manufacturer reserves the right to change the specification of the product or its performance or the contents of the User
Guide without notice. This User Guide is for use with version 2.30 or later Firmware.
Invertek Drives Ltd adopts a policy of continuous improvement and whilst every effort has been made to provide accurate and up to date
information, the information contained in this User Guide should be used for guidance purposes only and does not form the part of any
contract.
Optidrive P2 Elevator User Guide V2.30
