Mechanical dimensions – IP55 Units
Drive A B
Size
mm in mm
4 450 17.72 428
5 540 21.26 515
6 865 34.06 830
Mechanical Installation
Optidrive P2 Elevator User Guide V2.30
C D
in mm in mm in
16.85 433 17.05 8 0.31
20.28 520 20.47 8 0.31
32.68 840 33.07 10 0.39
Mounting Bolts
Frame Size Metric UNF
4 M8 #8
5 M8 #8
6 M10 5/16
www.InvertekDrives.com
E F
mm in mm in mm
252 9.92 171 6.73 110
270 10.63 235 9.25 175
330 12.99 330 12.99 200
Tightening Torques
Frame Size
Control Terminals All
4
Power Terminals 5
6
G H I
in mm in mm
4.33 4.25 0.17 7.5
6.89 4.25 0.17 7.5
7.87 5.5 0.22 11
Required Torque
0.5 Nm 4.5 lb-in
2 Nm 18 lb-in
4 Nm 35.5 lb-in
15 Nm 11 lb-ft
11
Weight
in kg lb
0.30 11.5 25.4
0.30 23 50.7
0.43 55 121.2
