Ethernet Module Features - 3Com NETBUILDER II Installation Manual

1-4 C 1: O
HAPTER VERVIEW
Ethernet Module
Features
Table 1-4 summarizes the Ethernet module features.
Table 1-4 Ethernet Module Features
Feature
Hot-swap capability
Cable support
Compatibility
Self-test and diagnostic
capability
Accessible information on
the EEPROM
Summary
Can be inserted or removed without turning off or rebooting the
NETBuilder II base system.
Supports all Ethernet media through an external transceiver.
Uses a BNC connector that supports network segments of up to 305
meters (1000 feet) for thin Ethernet coaxial cable (RG58 C/U or A/U
when using all 3Com transceivers). An AUI connector supports
network segments of up to 1000 meters (3280 feet) for thick Ethernet
cable.
Monitors network and signals status via LEDs.
Provides Ethernet module product information and repair data that
can be accessed via the monitor utility. Refer to the NETBuilder II Base
Installation Guide for details on accessing EEPROM information.
