B
S
PECIFICATIONS
Table B-1 lists the operating attributes and physical dimensions of the Ethernet
module.
Table B-1 Physical Dimensions and Operating Attributes
Attribute
Length
Width
Height
Board
Connector/LED panel
Weight
External transceiver
Ethernet data rate
Refer to the NETBuilder II Base System Installation Guide for a detailed list of minimum
and maximum electrical and environmental requirements for the Ethernet module.
Table B-2 lists the maximum current consumption for the Ethernet module.
Table B-2 Maximum Current Consumption
+5 Volts -5 Volts
1.0 amps 0.0 amps
Description
3.9 inches (9.9 cm)
8.8 inches (22.4 cm)
0.6 inches (1.52 cm)
1.0 inches (25 cm)
0.75 lbs (0.34 kg)
15-pin AUI connector
10 Mbps
+12 Volts
0.5 amps
-12 Volts
0.0 amps
