A
Electrical
Specifications
Environmental
Specifications
S
PECIFICATIONS
This appendix lists specifications for the 24-Port module. Also included
in this appendix is information on 50-pin Telco and twisted pair cables
and connectors. There are six subsections:
Electrical Specifications
Environmental Specifications
Mechanical Specifications
General Specifications
50-Pin Connector and Cable
Twisted Pair Connectors and Cables
Backplane Interface: Two 96-pin edge connectors, compatible with
3Com's CoreBuilder 5000 hub
Power Requirements: 3.5 A for 5V
Fuse: 10.0 Amps Fast blow
Watts: +5V = 17 Watts; +12V = .102 Watts; -5V = .108 Watts; +2V =
.008 Watts
Operating Temperature: 0° to 50° C (32° to 122° F)
Storage Temperature: -30° to 65° C (-22° to 149° F)
Humidity: less than 95%, non-condensing
BTU/hr: 61
