DELTA ELEKTRONIKA B.V.
DC POWER SUPPLIES
SM3000-se ries
SM 15 - 200 D
•
SM 30 - 100 D
•
SM 45 - 70 D
•
SM 70 - 45 D
•
SM 120 - 25 D
•
SM 300 - 10 D
•
PROD UCT MAN UAL
Con tents:
1 - Datasheet
2 - Safety Instructions
3 - Descriptions
4 - Operating,Trouble Shooting, Calibration
5 - EC Declaration of Conformity
Vissersdijk 4, 4301 ND
www.DeltaPowerSupplies.com
Zierikzee, the Netherlands
Tel. +31 111 413656
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Delta Elektronika SM15-200D
Summary of Contents for Delta Elektronika SM15-200D
- Page 1 Vissersdijk 4, 4301 ND www.DeltaPowerSupplies.com DELTA ELEKTRONIKA B.V. DC POWER SUPPLIES Zierikzee, the Netherlands Tel. +31 111 413656 SM3000-se ries SM 15 - 200 D • SM 30 - 100 D • SM 45 - 70 D • SM 70 - 45 D •...
-
Page 2: Ac Input Ratings
Failure to comply with the safety precautions or warnings in this document violates safety standards of design, manufacture and intended use of this equipment and may impair the built-in protections. Delta Elektronika shall not be liable for user’s failure to comply with these requirements. -
Page 3: Environmental Conditions
Unscrew the screws and remove the cover(s). • Always place the cover(s) back before connecting the unit to the mains supply again. 12 Environmental Conditions The Delta Elektronika power supplies safety approval applies to the following operating conditions: • Indoor use •... - Page 4 SM 120-25 D SM 70-45 D SM 300-10 D The SM15-200D, SM30-100D, SM45-70D, SM70-45D, SM120-25D and SM300-10D can ei ther be used as a con stant volt age source with cur rent lim it ing or as a con stant cur rent source with volt age lim it ing.
-
Page 5: Rip Ple & Noise
For us ing Imon on a pul sat ing load, see para graph 17) of this chapter. Vmon Imon 0-5V 0-5V Return of ref, prog, mon. fig. 3 - 8 Ex ter nal me ters us ing mon i tor out puts Page 3 - 2 DELTA ELEKTRONIKA B.V. rev. February 2018... -
Page 6: Status Out Puts
3 - 12 op er a tion. Con sult fac tory for ad vice. Also the output rip ple is higher. Con nec tions AN A LOG PROG. CONN. rev. February 2018 DELTA ELEKTRONIKA B.V. Page 3 - 3... -
Page 7: Re Covery Time
(see fig. 3 - 16). Like this the AC-com po nent caused by the pul - sat ing of the load is fil tered. fig. 3 - 15 With pul sat ing loads the I-monitor out put should not be used. Pul sating load current Page 3 - 4 DELTA ELEKTRONIKA B.V. rev. February 2018... -
Page 8: Phase Loss
How ever the out put rip ple volt age will be slightly higher when the in put is on one phase. fig. 3 - 19 Hold-up time vs Vout with Vin as a parameter rev. February 2018 DELTA ELEKTRONIKA B.V. Page 3 - 5... -
Page 9: Master/Slave Operation
Note: The Ther mal ShutDown and Re mote ShutDown will also cause the PSC-488 or the PSC-232 OVP-led to burn and the OVP-status will be high. Page 3 - 6 DELTA ELEKTRONIKA B.V. rev. February 2018... - Page 10 3 - 26 Screw driver ad just ment at rear panel fig. 3 - 27 The fan blows through a tun nel, where the heatsinks are sit u ated rev. February 2018 DELTA ELEKTRONIKA B.V. Page 3 - 7...
-
Page 11: Circuit Description
3 - 28 Sim pli fied func tional di a gram Page 3 - 8 DELTA ELEKTRONIKA B.V. rev. February 2018... -
Page 12: Op Er Ating The Unit For The First Time
When the power sup ply is used on a fixed out put volt age it is • highly rec om mended to set the Over Volt age Pro tec tor. As set out in the fol low ing ta ble: SM15-200D SM30-100D SM45-70D SM70-45D SM120-25D SM300-10D Vout + 2 V Vout + 3 V... -
Page 13: Battery Charger
3 - 9 . A prac ti cal choice for the fuses is 250 mA, the di odes can be any nor mal 3 or 5 A type. Page 4 - 2 DELTA ELEKTRONIKA B.V. rev. February 2018... -
Page 14: Master / Slave Series Op Er A Tion
4 - 11 The Mas ter / Slave Ser ies Adapter, MASTER / SLAVE SERIES OP ER A TION sup plied by Delta Elektronika For se ries op er a tion the MAS TER / SLAVE SE RIES ADAP- •... - Page 15 Mas ter / Slave par al lel connections fig. 4 - 14 Mas ter / Slave mixed se ries - par al lel con nec tions with two MAS TER / SLAVE SE RIES ADAPT ERS Page 4 - 4 DELTA ELEKTRONIKA B.V. rev. February 2018...
-
Page 16: Operating And Storage Conditions
It is ad vis able to in spect the fan and the heat sinks reg u larly. • rev. February 2018 DELTA ELEKTRONIKA B.V. Page 4 - 5... -
Page 17: Troubleshooting
Check link be tween pin 9 and 11 on the prog. con nec tor of the • slaves Cur rent shar ing is not ok. Prob a bly the links be tween S– and – of • the slaves are not re moved. Page 4 - 6 DELTA ELEKTRONIKA B.V. rev. February 2018... - Page 18 Note: Do not try to re pair P433, but send the sub unit with 2x P433 for re pair or ask for re place ment. Pref er a bly con sult fac tory when you dis cover a de fect in P433. rev. February 2018 DELTA ELEKTRONIKA B.V. Page 4 - 7...
-
Page 19: Meter Calibration
Model .....SM 30-100 D Se rial no..Sn821701900017 BSU no...Bs816802900036 Com po nent..D300 Description..BYV52-PI-200 fig. 4 - 21 On P384, CC mon i tor can be cal i brated Page 4 - 8 DELTA ELEKTRONIKA B.V. rev. February 2018... - Page 20 SM3000 EC DECLARATION DELTA ELEKTRONIKA B.V. Vissersdijk 4, 4301 ND www.DeltaPowerSupplies.com DC POWER SUPPLIES Zierikzee, the Netherlands Tel. +31 111 413656 EC Dec la ra tion of Con for mity - SM3000-series Delta Elektronika Vissersdijk 4 4301 ND ZIERIKZEE The Neth er lands...
