- Page 1 SM 15-100 SM 1500 - se ries • SM 35-45 • SM 52-30 • SM 52-AR-60 • SM 70-22 • SM 120-13 • SM 300-5 • SM 400-AR-8 • Elso Philips Service Jilemnického 2; 911 01 Trenèín tel: +421 32 6582410, 7431690 fax: +421 32 6582592 email:...
- Page 2 Parts Substitutions & Modifications Parts sub sti tu tions and mod i fi ca tions are al lowed by au tho rized Delta Elektronika ser vice per son nel only. For re pairs or mod ifications the unit must be re turned to a Delta Elektronika ser vice facility.
- Page 3 SM1500 Environmental Conditions The Delta Elektronika power supplies safety approval applies to the following operating conditions: In door use Am bi ent tem per a ture : −20 to 50 °C : 95%, non con densing, up to 40 °C Maximum rel ative hu midity : 75%, non con densing, up to 50 °C...
- Page 4 SM1500 DELTA ELEKTRONIKA BV DESCRIPTIONS SM 15-100 SM 35-45 OUT PUT The SM15-100, SM35-45, SM52-30, SM52-AR-60, SM70-22, SM120-13, SM300-5 and the SM400-AR-8 can ei ther be used as a con stant volt age source with cur rent limiting or as a con stant cur rent source with voltage lim it- ing.
- Page 5 ETHERNET / IEEE488 / RS232 PRO GRAMMING The Delta Elektronika PSC-ETH, PSC-488 and the PSC-232 con trol lers can be built in side the unit. Voltage and cur rent can easily be pro grammed and read back. Also all the status outputs can be read by the computer.
- Page 6 SM1500 DELTA ELEKTRONIKA BV fig. 3 - 8 Location of out put terminals and an alog pro gramming connector on the rear panel (unit with op tional PSC-488) CON A In ter lock Con nec tor para graph 18) CON B...
- Page 7 DELTA ELEKTRONIKA BV SM1500 Switch no. ON po si tion OFF po si tion De fault Set ting SW 1 - 1 Pro gramming via 15pole con - Op tional pro gram ming with e.g. ON (up) nector CON E (an alog).
- Page 8 SM1500 DELTA ELEKTRONIKA BV Warn ing! The 3750 Vrms can not be tested af terwards on the as sem bled unit be cause the in su la tion be tween the com po - nents on the in put side to the case (like the bridge rec tifier) is spec i fied at 2500 Vrms.
- Page 9 DELTA ELEKTRONIKA BV SM1500 SERIES OP ER A TION Series op eration is al lowed up to 600 V total voltage. The power sup plies can be con nected in se ries without spe cial pre cautions. For eas ier con trol, Mas ter / Slave op eration is recommended (see fig. 3- 18).
- Page 10 SM1500 DELTA ELEKTRONIKA BV VOLTAGE AND CUR RENT LIMIT The Voltage and Cur rent Limits maintain the output to a safe pre set value. They do not trip, so no re setting is needed after a fault. It can be very handy to have hard ware lim its when the power sup ply is pro grammed.
- Page 11 DELTA ELEKTRONIKA BV SM1500 OPERATING MANUAL OPERATING THE UNIT FOR THE FIRST TIME Check there is no con densation on the unit. If there is, al low some • time to dry. Check there is a link be tween + and S+ and be tween – and S– on •...
- Page 12 SM1500 DELTA ELEKTRONIKA BV Connect the pro gramming voltage source(s) (0 - 5 V) to the • analog pro gramming con nector CON E on the rear panel (see fig. 4 - 2 and fig. 4 - 3). Al ways use a shielded ca ble (max. 30 me ter) for pro gram ming.
- Page 13 DELTA ELEKTRONIKA BV SM1500 This feature is not rec ommended for normal use, be cause Suggested circuit breakers for pro tection power sup ply it can eas ily give prob lems. Model Type num ber Brand Re marks Max. 2 V per load lead can be compensated. Note that the •...
- Page 14 SM1500 DELTA ELEKTRONIKA BV If the ca ble is in serted when the unit is turned on, the output shuts down, the unit changes to Re mote CV / CC, the Keylock will be activated and the out put will turn back on.
- Page 15 DELTA ELEKTRONIKA BV SM1500 OPERATING AND STORAGE CONDITIONS TEM PER A TURE The op erating tem perature range at full load is –20 to +50 °C. • But this tem perature range only holds when the AIR-INTAKE and AIR-OUTLET are un obstructed and the temperature of the AIR-INTAKE is not higher than +50 °C.
- Page 16 SM1500 DELTA ELEKTRONIKA BV TROUBLE SHOOTING GEN ERAL In case you need as sistance for re pairing a unit, please con tact • our en gineers us ing the ad dress "Support@Delta-Elektronika.nl". In case you want us to re pair the unit, please first fill out the •...
- Page 17 DELTA ELEKTRONIKA BV SM1500 MASTER / SLAVE PAR ALLEL PROB LEMS Check the voltage drop of the wir ing be tween the master and the • slaves is < 10 mV. Check the wiring has a low in ductance. •...
- Page 18 SM1500 DELTA ELEKTRONIKA BV CALIBRATION GEN ERAL The power supplies are factory calibrated • and nor mally need no further cal ibration. Only in spe cial sit u a tions (for ex am ple af ter repairing a unit) cal ibration can be nec es- sary.
- Page 19 TEL. +31 111 413656 FAX. +31 111 416919 www.DeltaPowerSupplies.com EC Dec la ra tion of Con for mity Delta Elektronika P.O. BOX 27 4300 AA ZIERIKZEE The Neth er lands de clare un der sole re spon si bil ity that the fol low ing Power Sup plies:...
