Group ID Parameter
0.0 Focus
0.1 Instantaneous autofocus
0.2 Aperture (f-stop)
0.3 Aperture (normalised)
0.4 Aperture (ordinal)
Instantaneous
0.5
auto aperture
Lens
Optical image
0.6
stabilisation
0.7 Set absolute zoom (mm)
Set absolute zoom
0.8
(normalised)
Set continuous
0.9
zoom (speed)
1.0 Video mode
1.1 Sensor Gain
1.2 Manual White Balance
Video
1.3 Set auto WB
1.4 Restore auto WB
1.5
Exposure (us)
1.6 Exposure (ordinal)
1.7 Dynamic Range Mode
1.8
Video sharpening level
Type Index
fixed16 –
void –
fixed16 –
fixed16 –
int16 –
void –
boolean –
int16 –
fixed16 –
fixed16 –
[0] = frame rate
[1] = M-rate
int8 [2] = dimensions
[3] = interlaced
[4] = colour space
int8 –
int16 color temp
int16 tint
void –
void –
int32
int16 –
int8 enum –
int8 enum –
Minimum Maximum
0 1
– –
-1 16
0 1
0 n
– –
– –
0 max
0 1
-1 +1.0
– –
– –
– –
– –
– –
1 16
2500 10000
-50 50
– –
– –
1 42000
0 n
0 1
0 3
Informazioni per sviluppatori (English)
Interpretation
0.0=near, 1.0=far
trigger
instantaneous autofocus
Aperture Value (where
fnumber = sqrt(2^AV))
0.0=smallest, 1.0=largest
Steps through available
aperture values from
minimum (0) to maximum (n)
trigger instantaneous
auto aperture
true=enabled,
false=disabled
Move to specified focal
length in mm, from
minimum (0) to
maximum (max)
Move to specified focal
length: 0.0=wide, 1.0=tele
Start/stop zooming at
specified rate: -1.0=zoom
wider fast, 0.0=stop,
+1=zoom tele fast
24, 25, 30, 50, 60
0=regular, 1=M-rate
0=NTSC, 1=PAL, 2=720,
3=1080, 4=2k, 5=2k DCI,
6=4k, 7=4k DCI
0=progressive, 1=interlaced
0=YUV
1x, 2x, 4x, 8x, 16x gain
Colour temperature in K
tint
Calculate and set auto
white balance
Use latest auto white
balance setting
time in us
Steps through
available exposure
values from minimum (0)
to maximum (n)
0 = film, 1 = video
–
