6�1

LED displays

Power-LED
On indicates that power is present on the external screw
terminals or – with model 58665 – via PoE.
Status-LED
Rapid continuous flashing = bootup, no IP
Rapid continuous flashing (approx. 3x/s) indicates that
the Com-Server is in the bootup phase and/or has not yet
been assigned an IP address. Please use WuTility for ex-
ample to assign the Com-Server an IP address.
Slow continuous flashing = connection
Periodic flashing (1/s) indicates that the port has a valid
connection to another network station. The status of the
serial port can also be read out using WBM or the Com-
Server's Telnet configuration tool.
Error-LED
The Error LED uses various flashing patterns to indicate
error conditions on the device or serial port. The error
texts for the previous five serial faults and the associated
system time (time between the last restart of the Com-
Server and when the error occured) can also be read out
using the Telnet configuration tool.
Rapid continuous flashing = IP address conflict
The IP Address Conflict Detect function is activated and
the Com-Server has detected an IP address conflict. This
means the current IP address of the Com-Server is also
used by other stations in the network. To prevent further
problems, please contact the responsible network adminis-
trator and have the conflict resolved.
42
Error
Power Status
Error
Power Status
Error
Power Status
LED displays
