System Components
Mounting Using Base Mounting Plate
You can mount the Visionscape
plate that is supplied with the camera (see Figure 2–5).
FIGURE 2–5.
2-6
Base Mounting Plate
¼-20 threaded
mounting hole
6 mm from edge
Top View
Side View
Visionscape GigE Camera Guide
®
GigE Camera using the base mounting
Length: 47 mm
Width: 36 mm
v4.1, November 2011
