Chapter 2
System Components

Mode/Status LEDs

Figure 2–3 shows the mode and status LEDs.
FIGURE 2–3.
Table 2-2 describes the mode and status LEDs.
TABLE 2–2.
LED
1
2

Important Label Information

Each Visionscape
important information about that camera.
• P/N – The Microscan part number of your Visionscape GigE Camera.
• S/N — The serial number of your Visionscape GigE Camera.
• MAC — The MAC address of your Visionscape GigE Camera.
• Type — The model type of your Visionscape GigE Camera.
2-4
Mode/Status LEDs
Mode/Status LEDs
Color
Green
Yellow
Green
Green Flashing
Yellow
Yellow/Red Flashing
®
GigE Camera has its own label, which contains
Visionscape GigE Camera Guide
Function
Power On
Readout Active
Link Active
Receiving
Transmitting
Receiving and Transmitting
v4.1, November 2011
