Chapter 1
Introduction

Package Contents

Before you install Visionscape software and connect your Visionscape
GigE Camera, please take a moment to confirm that the following items
are available:
• Visionscape GigE Camera — Your package contains one of the
available GigE Camera models listed on the next page (see
Table 1–1)
• Visionscape Software Installation CD
• Visionscape 4.1 License Key
• Required accessories such as a power supply or power cable and
CAT6 network cable
®
Visionscape GigE Camera Models
Table 1–1 lists and describes the Visionscape GigE Camera models,
including acquisition modes and resolutions.
TABLE 1–1.
Part Number
98-000113-01 CMGC03
98-000114-01 CMGC03C
98-000115-01 CMG03
98-000116-01 CMG03C
98-000141-01 CMG04
98-000117-01 CMG08
98-000118-01 CMG13
98-000119-01 CMG20
98-000120-01 CMG50
98-000121-01 CMG03-P
1-4
®
Visionscape GigE Camera Models and Resolutions
Visionscape GigE
Camera Model
VGA Mono CMOS
VGA Color CMOS
VGA Mono CCD
VGA Color CCD
VGA Mono CCD – 1/2"
Sensor
XGA Mono CCD
SXGA Mono CCD
UXGA Mono CCD
QSXGA Mono CCD
VGA Mono CCD POE
Visionscape GigE Camera Guide
Sensor
Resolution
Size
752 x 480 1/3"
748 x 476 1/3"
656 x 494 1/3"
656 x 490 1/3"
656 x 494 1/2"
1032 x 776 1/3"
1392 x 1040 1/2"
1624 x 1236 1/1.8"
2448 x 2050 2/3"
656 x 494 1/3"
v4.1, November 2011
FPS
60
60
90
90
57
28
20
16
15
90
