System Components; Basic Components - Microscan Visionscape CMGC03 Manual

2
CHAPTER 2
This section contains information about system components as well as
information to help you connect the Visionscape
information describes connectors, adapters, cables, pinouts, signals, and
network configuration.
Note: There are no user-serviceable parts inside.

Basic Components

Table 2-1 lists the Visionscape
Note: CMOS Visionscape GigE cameras (CMGC03 and CMGC03c – 98-
000113-01 and 98-000114-01) do not report trigger overrun (too-fast
trigger) conditions. These cameras should not be specified for high trigger
rate applications where overruns may occur.
TABLE 2–1.
Part Number Description
Cameras
98-000113-01 Visionscape
98-000114-01 Visionscape
98-000115-01 Visionscape
v4.1, November 2011

System Components

®
Visionscape GigE Camera Hardware Components
®
GigE Camera – VGA Mono CMOS
®
GigE Camera – VGA Color CMOS
®
GigE Camera – VGA Mono CCD
Visionscape GigE Camera Guide
®
GigE Camera. Specific
®
GigE Camera hardware components.
2
2-1
