Phone Installation Instruction
1. Pull out the holder until the phone can be hold( Picture 7), then unfold the
lower clamp( Picture 8).
2. Put the phone into the holder, then release the clamp, and the phone will be
fixed on the holder( Picture 9/10).

Picture 7

Notice: Make sure that the button on phone is not clamped.
Installing & Removing Component
Charging Instruction for Drone Battery
1. Connect the drone battery with USB cable first and then choose one of the
method as below picture shown to connect with USB plug.
2. The red USB indicator light keeps bright when charging and the light turns green
when fully charged.
* For faster charging, it is recommended to use an adapter with 5V 2A output current (not included)
to charge the battery
Phone Charger Power Bank
Drone Battery Li-Po Battery Disposal & Recycling
Wasted Lithium-Polymer batteries must not be placed with household
trash. Please contact local environmental or waste agency or the
supplier of your model or your nearest Li-Po battery recycling center.
Picture 8
Computer Charging Car Charger
8
www.udirc.com
Picture 9 Picture 10
Drone Battery
