Battery - UDI R/C U29 Plus WIING+ User Manual

High/Medium/Low
Speed Mode
Controller Button Functions
High / Medium/Low Speed button:
Left Stick: Move the Stick to forward / backward / left / right to fly the drone up / down / turn left / turn right.
Right Stick: Move the Stick to forward / backward / left / right to fly the drone forward / backward / left / right.
Trimmer Mode Button:
Power Switch: Push up the power switch to turn on the controller, and pull down to turn off.
Heading Hold Mode: Press to enter Heading Hold Mode. Press again to exit Heading Hold Mode.
Take Off / Landing / Emergency Stop Button: Press once and the drone will take off automatically.
Press again and the drone will land automatically. Press and hold the button for more than 1 second for
an emergency landing. The drone propellers will stop and it will land immediately.
Battery Installation
Open the battery cover on the back side of the controller, insert 4 AA batteries,
following the polarity indicators. ( Picture 5/6, battery is not included)
Picture 5
Notice:
1.Make sure the electrodes are correct.
3.Do not mix different kinds of batteries.
Press to switch to High /Medium/ Low Speed.
Press this button and move the right stick to the required trimmer direction, then it
will adjust the direction accordingly. Release the stick to end trimmer mode.
4 x 1.5V
Alkaline Battery
Battery Cover
2.Do not mix new with old batteries.
4.Do not charge the non rechargeable battery.
7
www.udirc.com
Trimmer Mode Button
Battery Cover
Picture 6
